凯斯零件查询(LB424S XL) - BALER (11/16-) (60.240.051) - PACKER CLUTCH - D151 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
390 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47607495
|
[1] |
SLIP CLUTCH
|
ZED
Incl 2 - 19
|
| 2. |
47606755
|
[1] |
SPROCKET
|
ZED
|
| 3. |
47809156
|
[1] |
BUSHING
|
ZED
|
| 4. |
47582706
|
[1] |
CLUTCH DISC
|
ZED
|
| 5. |
47853054
|
[5] |
DISC
|
ZED
|
| 6. |
47583605
|
[5] |
CLUTCH DISC
|
ZED
|
| 7. |
47583777
|
[3] |
PIN
|
ZED
|
| 8. |
84041833
|
[2] |
CIRCLIP
|
ZED
|
| 9. |
47607399
|
[1] |
HUB
|
ZED
|
| 10. |
47610423
|
[1] |
DISC
|
ZED
|
| 11. |
84036158
|
[1] |
BUSHING,74.94mm ID x 80mm OD x 20mm L
|
ZED
|
| 12. |
47584626
|
[9] |
TUBE
|
ZED
|
| 13. |
9820493
|
[18] |
WASHER,20.5mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 14. |
47664595
|
[9] |
COMPRESSION SPRING
|
ZED
|
| 15. |
9832748
|
[9] |
WASHER
|
ZED
Superseded by part number: 140042
|
| 16. |
326100
|
[9] |
BOLT,Hex, M10 x 1.5 x 170mm, Cl 8.8
|
ZED
|
| 17. |
322359
|
[3] |
BELLEVILLE WASHER,M20 Bolt Size x 40mm OD x 3.2mm Thk
|
NH
|
| 18. |
84015548
|
[3] |
NUT,M20 x 1.5, Cl 8.8
|
ZED
, Serial Range: -C159
|
| 18. |
100085
|
[3] |
NUT,M20 x 1.5, Cl 8
|
NH
, Start Serial: D160
|
| 19. |
48023620
|
[1] |
SHIM
|
ZED
, Start Serial: D160
|
