神钢零件查询(K909LC) - MARK II EXCAVATOR ASN LLU-0001 (1/87-12/03) (11-009) - VALVE ASSY, HOLDING, 2436R767 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
741 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R767F1 | [1] | VALVE ASSY, HOLDING, CONSISTS OF THE FOLLOWING PARTS | |
| 1. | 2436R764 | [1] | PLATE, SUB | |
| 2. | 2436U1311F1 | [1] | VALVE ASSY, HOLDING, SEE FIGURE 11-015 | |
| 3. | ZS23C14080 | [4] | SCREW,Hex Socket Head, M14 x 80mm | HITM14x2.0x80mm |
| 4. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 5. | 2436R764S2 | [1] | BAND ASSY, SUB-PLATE | BAND ASSY, SUB-PLATE |
| 5-1. | 2438U914D1S24 | [1] | U-BRACKET | KOBBAND |
| 5-2. | 2436R764S2 | [1] | BAND SUB PLATE | BAND SUB PLATE |
| 5-3. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 5-4. | ZS11C10035 | [2] | SCREW,Hex, M10 x 35mm, Cl 4.8 | KOBCAPSCREW -- M10x1.50x35mm Superseded by part number: ZS18C10035 |
| 5-5. | ZS23C10025 | [2] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 5-6. | ZN16C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
