凯斯零件查询(LB424S XL) - BALER (11/16-) (70.200.010) - PLUNGER RAILS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
759 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9837987
|
[4] |
LEVER
|
ZED
|
| 2. |
84806594
|
[4] |
SPRING
|
ZED
|
| 3. |
51639
|
[8] |
WASHER,16.5mm ID x 41.3mm OD x 3.5mm Thk
|
ZED
|
| 4. |
43874
|
[4] |
BOLT,Hex, M16 x 110, 8.8
|
NH
, Serial Range: -C139
|
| 4. |
321246
|
[4] |
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8
|
NH
, Start Serial: D140
|
| 5. |
86000441
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 6. |
84801492
|
[2] |
GUIDE
|
ZED
, Serial Range: -C150
|
| 6. |
47930612
|
[2] |
CROSSRAIL
|
ZED
, Start Serial: D151
|
| 7. |
72181588
|
[12] |
HEX SOC SCREW,Flat Hd, M10 x 35mm, Cl 8.8
|
BER
Superseded by part number: 72181589
|
| 8. |
140042
|
[14] |
WASHER,11mm ID x 34mm OD x 3mm Thk
|
GI
, Serial Range: -C150
|
| 8. |
140046
|
[14] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
, Start Serial: D151
|
| 9. |
412141
|
[12] |
NUT,M10 x 1.5, Cl 8
|
ZED
Superseded by part number: 190003888452
|
| 10. |
9837986
|
[2] |
GUIDE
|
ZED
|
| 11. |
84444574
|
[4] |
ADJUSTING PLATE
|
ZED
|
| 12. |
84444575
|
[12] |
SHIM,60mm OD x 0.5mm Thk
|
ZED
|
| 13. |
378244
|
[12] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 14. |
87654459
|
[14] |
SCREW
|
CUR
, Start Serial: D151
|
| 15. |
337475
|
[14] |
NUT,M12, Cl 10
|
BHB
, Start Serial: D151
|
| 16. |
47930347
|
[14] |
BUSHING
|
ZED
, Start Serial: D151
|
