凯斯零件查询(LB424S XL) - BALER (11/16-) (70.280.015) - STANDARD BALE EJECTION MECHANISM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
977 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47815303
|
[8] |
BLOCK
|
ZED
|
| 2. |
47955587
|
[4] |
PLATE
|
ZED
|
| 3. |
47955588
|
[4] |
PLATE
|
ZED
|
| 4. |
47955576
|
[4] |
BLOCK
|
ZED
|
| 5. |
47815279
|
[10] |
TOOTH
|
ZED
|
| 6. |
47819750
|
[22] |
BUSHING
|
ZED
|
| 7. |
47815277
|
[2] |
TOOTH
|
ZED
|
| 8. |
47819722
|
[2] |
PLATE
|
ZED
|
| 9. |
47955590
|
[4] |
PLATE
|
ZED
|
| 10. |
47955584
|
[4] |
PLATE
|
ZED
|
| 11. |
47819723
|
[2] |
PLATE
|
ZED
|
| 12. |
47819717
|
[14] |
SHAFT
|
ZED
|
| 13. |
370024
|
[28] |
CIRCLIP,M20, Ext
|
NH
|
| 14. |
412346
|
[12] |
BOLT,Hex, M20 x 2.5 x 90mm, Cl 8.8
|
NH
|
| 15. |
13580001
|
[12] |
WASHER,21mm ID x 36mm OD x 0.5mm Thk
|
IMO
|
| 16. |
380424
|
[22] |
NUT,M20 x 2.5, Cl 8
|
FOR
|
| 17. |
86601713
|
[6] |
BOLT,Hex, M20 x 65mm, Cl 8.8, Full Thd
|
PA
|
| 18. |
390071
|
[2] |
CLEVIS PIN,M16 x 45
|
ZED
|
| 19. |
130007
|
[2] |
COTTER PIN,M4 x 25
|
NH
Superseded by part number: 83903970
|
| 20. |
47967384
|
[4] |
SHAFT
|
ZED
|
| 21. |
370002
|
[8] |
CIRCLIP,M25, External
|
NH
|
| 22. |
47815258
|
[1] |
CROSSRAIL
|
ZED
|
| 23. |
440588
|
[4] |
BOLT,Hex, M20 x 70, 8.8
|
NH
Superseded by part number: 80440588, 15224121
|
