| 1. |
84517042
|
[1] |
DIVIDER
|
ZED
Incl 2 - 11, 25, 26
|
| 2. |
84395055
|
[1] |
DIVIDER
|
ZED
8/8
|
| 3. |
87670206
|
[1] |
FITTING
|
ZED
Superseded by part number: 2928866
|
| 4. |
84807301
|
[5] |
END FITTING
|
ZED
|
| 5. |
84807292
|
[2] |
HYD CONNECTOR
|
ZED
Superseded by part number: 2928867
|
| 6. |
84379934
|
[3] |
PLUG
|
ZED
Superseded by part number: 84807296
|
| 7. |
84379944
|
[1] |
HOSE
|
ZED
L=3.03M Superseded by part number: 84807289
|
| 8. |
84388052
|
[6] |
SCREW ON COUPLING
|
ZED
Superseded by part number: 1431140, 1431139
|
| 9. |
84388050
|
[1] |
HOSE
|
ZED
L=3.97M Superseded by part number: 84807290
|
| 10. |
84807304
|
[1] |
LUBE NIPPLE
|
ZED
|
| 11. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Fitting Incl in 1
|
| 12. |
84807240
|
[2] |
NIPPLE
|
ZED
, Serial Range: -C084
|
| 12. |
84807241
|
[2] |
NIPPLE
|
ZED
, Start Serial: D085
|
| 14. |
84818125
|
[1] |
ELBOW UNION
|
ZED
|
| 15. |
84818442
|
[1] |
CLAMP,13.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 16. |
86010402
|
[1] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 17. |
84818444
|
[1] |
CLAMP,22.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
, Serial Range: -C084
|
| 17. |
9837593
|
[1] |
CLAMP
|
ZED
, Start Serial: D085
|
| 18. |
445395
|
[3] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 19. |
140015
|
[1] |
WASHER,6.4mm ID x 14mm OD x 1.6mm Thk
|
NH
Superseded by part number: 9820463
|
| 20. |
86977786
|
[1] |
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8
|
GI
|
| 21. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 22. |
120056
|
[2] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
, Serial Range: -C084
|
| 22. |
412364
|
[2] |
CARRIAGE BOLT,M6 x 1.0 x 56.6mm, Cl 8.8
|
ZED
, Start Serial: D085
|
| 23. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 24. |
86566990
|
[15] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 27. |
412152
|
[2] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 28. |
84439102
|
[2] |
SEALING WASHER,10mm ID x 16mm OD x 1.5mm Thk
|
ZED
, Serial Range: -C084
|
| 29. |
84807248
|
[1] |
HYD CONNECTOR
|
ZED
|
| 30. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
Superseded by part number: 47560081, 47560080
|
| 31. |
84807247
|
[1] |
COUPLING
|
ZED
, Start Serial: D085
|
| 33. |
84310718
|
[1] |
FITTING
|
ZED
, Start Serial: D085
|
| 34. |
84818443
|
[2] |
CLAMP,16.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
, Start Serial: D085
|
| 35. |
9512289
|
[1] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
PLO
, Start Serial: D085
|
