凯斯零件查询(LB424S XL) - BALER (11/16-) (71.460.070) - CENTRAL GREASING, PACKER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
469 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84341268
|
[1] |
NIPPLE
|
ZED
Incl 2 - 5
|
| 1. |
84341267
|
[1] |
NIPPLE
|
ZED
Incl 2 - 5
|
| 2. |
84379935
|
[1] |
NIPPLE
|
PLO
4-Apr
|
| 2. |
84379936
|
[1] |
BLOCK
|
ZED
6-Jun
|
| 3. |
84807375
|
[4] |
NIPPLE
|
ZED
|
| 4. |
84379944
|
[1] |
HOSE
|
ZED
L=5.79M Superseded by part number: 84807289
|
| 5. |
84388052
|
[4] |
SCREW ON COUPLING
|
ZED
Superseded by part number: 1431140, 1431139
|
| 6. |
43117
|
[2] |
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
|
NH
, Serial Range: -C084 Superseded by part number: 87317695
|
| 6. |
86512441
|
[2] |
CARRIAGE BOLT,Rnd Head, M6 x 1 x 36.6mm, Cl 8.8
|
GI
, Start Serial: D085
|
| 7. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 8. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 9. |
84449335
|
[1] |
CABLE TIE,346mm L
|
ZED
|
| 11. |
86566990
|
[10] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 12. |
431941
|
[2] |
SUPPORT
|
DUB
|
