凯斯零件查询(LB424S XL) - BALER (11/16-) (88.005.002) - DIA KIT: HANDS CLEANING DEVICE AND STORAGE BOX Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
322 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47964850
|
[1] |
DIA KIT, HARVESTER
|
COE
Incl 2 - 21
|
| 2. |
47999146
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84547204
|
[1] |
HOLDER
|
ZED
|
| 4. |
84423225
|
[1] |
RESERVOIR
|
ZED
Superseded by part number: 920018985
|
| 5. |
84423241
|
[1] |
STRAP
|
ZED
|
| 6. |
84593001
|
[1] |
BOX
|
ZED
|
| 7. |
47368966
|
[1] |
RUBBER PAD
|
ZED
|
| 8. |
120044
|
[7] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 9. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 10. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 11. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 12. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 14. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 15. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 16. |
87024930
|
[2] |
WASHER,10.8mm ID x 50mm OD x 3mm Thk
|
GI
|
| 17. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 18. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
331233
|
[8] |
PLUG
|
ZED
|
| 21. |
336455
|
[6] |
PLUG
|
ZED
|
