凯斯零件查询(LB424S XL) - BALER (11/16-) (88.039.007[01]) - DIA KIT: HYDRAULIC JACK KIT - D122 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
480 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47688896
|
[1] |
DIA KIT, HARVESTER
|
ZED
Incl 2 - 17
|
| 2. |
47689181
|
[1] |
HYDRAULIC JACK
|
ZED
|
| 3. |
84043514
|
[2] |
HYD CONNECTOR
|
ZED
|
| 4. |
87479525
|
[2] |
FITTING
|
PLO
|
| 5. |
87493574
|
[2] |
NUT
|
ZED
|
| 6. |
430356
|
[2] |
CLAMP
|
ZED
|
| 7. |
84814948
|
[1] |
SUPPORT
|
ZED
|
| 8. |
47416999
|
[2] |
HOSE
|
ZED
|
| 9. |
47637354
|
[2] |
HOSE
|
ZED
|
| 10. |
84819675
|
[2] |
PUSH-PULL COUPLING
|
ZED
|
| 11. |
325594
|
[3] |
WASHER,M17 x 40mm OD x 5mm Thk
|
ZED
|
| 12. |
140048
|
[3] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 13. |
84056523
|
[3] |
BOLT,Hex, M16 x 45mm, Cl 10.9
|
ZED
|
| 14. |
86592084
|
[2] |
DUST CAP
|
ZED
Superseded by part number: 86621124
|
| 15. |
9850685
|
[1] |
BOLT,Hex, M6 - 1 x 90mm, Cl 8.8
|
NH
Superseded by part number: 190003800038
|
| 16. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 17. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
