凯斯零件查询(LB424S XL) - BALER (11/16-) (88.055.017[01]) - DIA KIT: MOISTURE SENSOR - D085 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
847 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47510814
|
[1] |
DIA KIT, HARVESTER
|
ATT
Incl 2 - 18
|
| 2. |
47510805
|
[1] |
WIRE HARNESS
|
ZED
|
| 3. |
47510807
|
[1] |
WIRE HARNESS
|
ZED
|
| 4. |
84062460
|
[4] |
NUT
|
ZED
|
| 5. |
47467782
|
[1] |
MOUNTING PLATE
|
ZED
|
| 6. |
84471733
|
[1] |
ECU
|
ZED
|
| 7. |
87395156
|
[2] |
REGULATING SYSTEM
|
ZED
|
| 8. |
87395158
|
[1] |
GUARD
|
ZED
|
| 9. |
87395159
|
[1] |
GUARD
|
ZED
|
| 10. |
366046
|
[8] |
CARRIAGE BOLT,Sq Nk, M8 x 1.25 x 80mm, Cl 8.8
|
WIN
Superseded by part number: 120040
|
| 11. |
322358
|
[12] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 12. |
9706690
|
[20] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 13. |
120061
|
[4] |
BOLT,Hex, M8 x 60mm L, Cl 8.8
|
NH
|
| 14. |
11194079
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 16mm OD x 1.9mm Thk
|
TOR
Superseded by part number:
|
| 15. |
87380352
|
[1] |
ELEC CONNECTOR
|
ZED
|
| 16. |
86566990
|
[23] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 17. |
86010402
|
[2] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 18. |
84320044
|
[1] |
FUSE,5 Amp
|
ZED
Superseded by part number: 87693742
|
