神钢零件查询(K909LC) - MARK II EXCAVATOR ASN LLU-0001 (1/87-12/03) (06-007) - RING, SLEWING (LUBRICATION) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
648 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4119F1 | [1] | SLEWING RING | KOB |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONRING, SLEWING, SEE FIGURE 06-008 |
| 2. | 2418P12218 | [2] | TUBE | KOB |
| 3. | 2410T306 | [2] | KNUCKLE JOINT | KOB |
| 4. | ZF33E08004 | [2] | ELBOW | KOB |
| 5. | ZF23E08004 | [2] | HYD CONNECTOR | KOB |
| 6. | ZG91S02000 | [3] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 7. | ZC45X08007 | [2] | CLAMP | KOB Superseded by part number: ZC46X08007 |
| 8. | ZS13C06010 | [2] | SCREW | KOBM06x1.0x10mm Superseded by part number: ZS18C06010 |
