神钢零件查询(K909LC) - MARK II EXCAVATOR ASN LLU-0001 (1/87-12/03) (07-002) - ARM ASSY, 2.98M Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
356 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10756F3 | [1] | ARM ASSY 2.98M | ARM ASSY 2.98M |
| 2. | 2438U959F1 | [1] | CYLINDER | KOBCYLINDER |
| 3. | 2406N1454F1 | [1] | LINK CONROD | KOB |
| 3-8. | 2405T1263 | [2] | BUSHING | KOB |
| 3-9. | 2405T1264 | [2] | BUSHING | KOB |
| 4. | 2406P2617D1 | [1] | LINK CONROD | KOB |
| 5. | 2406P2617D2 | [1] | LINK CONROD | KOB |
| 6. | 2419P2953 | [1] | PIN | KOB Superseded by part number: 2419P4041 |
| 7. | 2419P2954 | [1] | PIN | PIN |
| 8. | 2419P1710D2 | [1] | PIN | KOB |
| 9. | 2419T4684D1 | [2] | PIN,90mm OD x 500mm L | KOB Superseded by part number: 2419T7611D1 |
| 10. | 2419P1679D1 | [1] | PIN | KOB |
| 11. | 2418T18163 | [1] | RIGID TUBE | KOB |
| 12. | 2418T17669 | [1] | RIGID TUBE | KOB |
| 13. | ZX56N12130 | [2] | HOSE | KOB |
| 14. | 2445R372D2 | [4] | DUST CAP | KOBSEAL |
| 15. | 2445R372D1 | [2] | DUST CAP | KOB |
| 16. | 2445R372D4 | [6] | DUST CAP | KOBSEAL |
| 17. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 18. | ZG91V02000 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| 19. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 20. | ZS13C16130 | [1] | SCREW | KOB |
| 21. | 2420T4330D2 | [2] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm Superseded by part number: HS18C16150G1 |
| 22. | ZS13C10070 | [8] | SCREW | KOBM10x1.50x70mm Superseded by part number: ZS18C10070 |
| 23. | ZS13C16140 | [1] | SCREW | KOBM16x2.0x140mm |
| 24. | ZS13C10055 | [1] | SCREW | KOBM10x1.50x55mm Superseded by part number: ZS18C10055 |
| 25. | ZN13C16013 | [8] | NUT | KOBM16x2.0mm |
| 26. | 2419T6002D1 | [2] | PIN,16mm OD x 115mm L | KOBOD 16 x 115mm Long |
| 27. | ZW22X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 28. | 2432T1187 | [1] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 29. | 2420R349D096 | [1] | HOSE | KOB Superseded by part number: HX21E04096DX |
| 30. | 2418T19206D1 | [2] | RING | KOB |
| 31. | ZC45X10009 | [2] | CLIP | KOB Superseded by part number: ZC46X10009 |
| 32. | ZN13C06005 | [2] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 33. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 34. | 2444Z2002 | [1] | HYD CONNECTOR | KOB1/8"PTx1/4"PFx32mm Long |
| 35. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 36. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 37. | B16T0442D4 | [2] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 38. | B16T0442D14 | [1] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
| 40. | 2411N2402F1 | [1] | ARM | ARM |
| 40-5. | 2418T17900 | [1] | SPACER | KOB |
| 40-6. | 2418T17497 | [1] | SPACER | KOB |
| 40-7. | 2405T1293 | [2] | BUSHING | KOB |
| 40-8. | B05T0041C2 | [2] | BUSHING | KOB |
| 40-9. | 2405T585C2 | [2] | BUSHING | KOB |
