凯斯零件查询(LB424S XL) - BALER (11/16-) (88.068.011[02]) - DIA KIT : BLOW OFF KIT WITH COMPRESSOR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
544 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47602289
|
[1] |
DIA KIT, HARVESTER
|
ZED
Incl 2 - 93
|
| 2. |
47781911
|
[2] |
90 ELBOW
|
ZED
|
| 3. |
47781910
|
[1] |
TUBE
|
ZED
|
| 4. |
47781972
|
[1] |
SUPPORT
|
ZED
|
| 5. |
47780171
|
[1] |
AIR COMPRESSOR
|
ZED
|
| 6. |
47781362
|
[4] |
DISC
|
ZED
|
| 7. |
47781364
|
[4] |
CARRIAGE BOLT
|
ZED
|
| 8. |
47781358
|
[1] |
PLATE
|
ZED
|
| 9. |
47781369
|
[1] |
ROD
|
ZED
|
| 10. |
47781310
|
[14] |
WASHER
|
ZED
|
| 11. |
47781920
|
[12] |
NUT
|
ZED
|
| 12. |
47781372
|
[1] |
PLATE
|
ZED
|
| 13. |
47781277
|
[13] |
NUT
|
ZED
|
| 14. |
47780252
|
[1] |
FITTING
|
ZED
|
| 15. |
47781384
|
[1] |
SEAL
|
ZED
|
| 16. |
47781914
|
[1] |
WRAPPER
|
ZED
|
| 17. |
47781921
|
[1] |
TUBE
|
ZED
|
| 18. |
47782080
|
[1] |
PIPE
|
ZED
|
| 19. |
47781923
|
[1] |
CAP
|
ZED
|
| 20. |
47780240
|
[1] |
AIR INTAKE TUBE
|
ZED
|
| 21. |
47780207
|
[1] |
FLANGE
|
ZED
|
| 22. |
47780178
|
[1] |
FLANGE
|
ZED
|
| 23. |
47780189
|
[1] |
PUMP
|
ZED
|
| 24. |
47780242
|
[1] |
COUPLING
|
ZED
|
| 25. |
47781331
|
[1] |
FITTING
|
ZED
|
| 26. |
47781339
|
[2] |
TUBE
|
ZED
|
| 27. |
47780232
|
[4] |
FITTING
|
ZED
|
| 28. |
47781335
|
[1] |
VALVE
|
ZED
|
| 29. |
47781216
|
[1] |
FITTING
|
ZED
|
| 30. |
47781180
|
[2] |
FITTING
|
ZED
|
| 31. |
47781359
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 32. |
47781365
|
[1] |
ELBOW
|
ZED
|
| 33. |
47781913
|
[1] |
AIR FILTER
|
ZED
|
| 34. |
47781186
|
[2] |
NUT
|
ZED
|
| 35. |
47781222
|
[1] |
NUT
|
ZED
|
| 36. |
47795540
|
[1] |
TUBE
|
ZED
|
| 37. |
47780259
|
[1] |
FLANGE
|
ZED
|
| 38. |
47780255
|
[1] |
PULLEY
|
ZED
|
| 39. |
47780257
|
[1] |
V-BELT
|
ZED
|
| 40. |
47781199
|
[1] |
PLATE
|
ZED
|
| 41. |
47781924
|
[1] |
SUPPORT
|
ZED
|
| 42. |
47781928
|
[1] |
ROD
|
ZED
|
| 43. |
47781314
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 44. |
47781324
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 45. |
47781205
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 335173
|
| 46. |
47781342
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 47. |
47781280
|
[1] |
HYDRAULIC HOSE
|
ZED
|
| 48. |
47781931
|
[1] |
TUBE
|
ZED
|
| 49. |
47781934
|
[1] |
TUBE
|
ZED
|
| 50. |
47780221
|
[8] |
HEX SOC SCREW
|
ZED
|
| 51. |
47780237
|
[1] |
SOCKET
|
ZED
|
| 52. |
47780234
|
[1] |
FITTING
|
ZED
|
| 53. |
47781285
|
[2] |
SCREW
|
ZED
|
| 54. |
47781378
|
[7] |
HOSE
|
ZED
|
| 55. |
47780180
|
[4] |
SCREW
|
ZED
|
| 56. |
47781203
|
[3] |
CARRIAGE BOLT
|
ZED
|
| 57. |
47781274
|
[11] |
WASHER
|
ZED
|
| 58. |
47780235
|
[2] |
RING
|
ZED
|
| 59. |
47781354
|
[2] |
SCREW
|
ZED
|
| 60. |
47781160
|
[8] |
WASHER
|
ZED
|
| 61. |
47781166
|
[8] |
NUT
|
ZED
|
| 62. |
86592700
|
[2] |
WASHER,10.5mm ID x 28mm OD x 4mm Thk
|
ZED
|
| 63. |
47781973
|
[4] |
SCREW
|
ZED
|
| 64. |
47781159
|
[6] |
SCREW
|
ZED
|
| 65. |
47781925
|
[2] |
SCREW
|
ZED
|
| 66. |
47781919
|
[2] |
WASHER
|
ZED
|
| 67. |
47781918
|
[2] |
SCREW
|
ZED
Superseded by part number: 47441806
|
| 68. |
47780251
|
[1] |
RING
|
ZED
|
| 69. |
47780244
|
[1] |
PLATE
|
ZED
|
| 70. |
47781282
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 71. |
47781295
|
[2] |
COUPLING
|
ZED
|
| 72. |
47780233
|
[4] |
RING
|
ZED
|
| 73. |
47781392
|
[1] |
SEAL
|
ZED
|
| 74. |
47781198
|
[2] |
SEAL
|
ZED
|
| 75. |
47781168
|
[1] |
TANK
|
ZED
|
| 76. |
47781387
|
[1] |
OIL SEAL
|
ZED
|
| 77. |
47781171
|
[1] |
COVER
|
ZED
|
| 78. |
47781178
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 79. |
47781175
|
[1] |
GLASS
|
ZED
|
| 80. |
47781225
|
[1] |
SUPPORT
|
ZED
|
| 81. |
47781244
|
[4] |
SCREW
|
ZED
|
| 82. |
47781172
|
[10] |
WASHER
|
ZED
Superseded by part number: 47441865
|
| 83. |
47781241
|
[4] |
NUT
|
ZED
|
| 84. |
47781177
|
[4] |
SCREW
|
ZED
|
| 85. |
47781176
|
[4] |
RUBBER BLOCK
|
ZED
|
| 86. |
47781304
|
[2] |
SCREW
|
ZED
|
| 87. |
47781930
|
[1] |
INDICATOR
|
ZED
|
| 88. |
47780215
|
[1] |
WASHER
|
ZED
|
| 89. |
47780218
|
[1] |
O-RING
|
ZED
|
| 90. |
47781380
|
[2] |
CARRIAGE BOLT
|
ZED
|
| 91. |
47781374
|
[1] |
PLATE
|
ZED
|
| 92. |
47781377
|
[1] |
PLATE
|
ZED
|
| 93. |
47781213
|
[4] |
CARRIAGE BOLT
|
ZED
|
