凯斯零件查询(LB424S XL) - BALER (11/16-) (88.070.021[01]) - DIA KIT: PARTIAL BALE EJECT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47964855
|
[1] |
DIA KIT, HARVESTER
|
ATT
Incl 2 - 13
|
| 2. |
47470677
|
[1] |
HYDRAULIC CYLINDER
|
ZED
|
| 3. |
84591579
|
[1] |
SHAFT
|
ZED
|
| 4. |
47658869
|
[2] |
PLATE
|
ZED
|
| 5. |
338949
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 6. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 7. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
47968807
|
[1] |
SLEEVE
|
ZED
|
| 9. |
47974621
|
[1] |
SLEEVE
|
ZED
|
| 10. |
87491174
|
[1] |
SHAFT
|
ZED
|
| 11. |
378247
|
[2] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 12. |
370024
|
[2] |
CIRCLIP,M20, Ext
|
NH
|
| 13. |
47815304
|
[1] |
LATH
|
ZED
|
