现代零件查询R370LC-7 UPPER HYDRAULIC PIPING(ATTACH, JEIL MCV)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
770 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
UPPER HYDRAULIC PIPING
|
|
| 1. |
31NA-14311
|
[1] |
HOSE ASSY
|
|
| 2. |
31NA-14321
|
[1] |
HOSE ASSY
|
|
| 3. |
31NA-14331
|
[1] |
HOSE ASSY
|
|
| 4. |
31NA-14341
|
[1] |
HOSE ASSY
|
|
| 5. |
31NA-14351
|
[1] |
HOSE ASSY
|
|
| 6. |
31NA-14361
|
[1] |
HOSE ASSY
|
|
| 7. |
31NA-13102
|
[4] |
HOSE ASSY-FLG(0X0)
|
|
| 8. |
31NA-12560
|
[1] |
PIPE WA-BOOM"LC"
|
|
| 9. |
31NA-12570
|
[1] |
PIPE WA-BOOM "SC"
|
|
| 10. |
31NA-13090
|
[1] |
BRACKET-BOOM PIPE
|
|
| 11. |
31EM-12170
|
[3] |
CLAMP-PIPE
|
|
| 12. |
S017-100706
|
[2] |
BOLT-HEX
|
|
| 13. |
S017-100856
|
[1] |
BOLT-HEX
|
|
| 14. |
S037-103026
|
[2] |
BOLT-W/WASHER
|
|
| 15. |
S109-100306
|
[16] |
BOLT-SOCKET
|
|
| 16. |
S109-120406
|
[24] |
BOLT-SOCKET
|
|
| 17. |
S205-10100B
|
[2] |
NUT-HEX
|
|
| 18. |
S411-100006
|
[3] |
WASHER-SPRING
|
|
| 19. |
P173-160104
|
[8] |
FLANGE-HYD,SPLIT
|
|
| 20. |
P174-200106
|
[12] |
FLANGE-HYD,SPLIT
|
|
| 21. |
Y171-024004
|
[4] |
O-RING
|
|
| 22. |
Y171-027004
|
[6] |
O-RING
|
|
| 23. |
S621-021001
|
[2] |
O-RING
|
|
| 24. |
S403-10100B
|
[2] |
WASHER-PLAIN
|
|
