神钢零件查询(K909LC) - MARK II EXCAVATOR ASN LLU-0001 (1/87-12/03) (10-001) - LABEL, NAME-PLATE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
145 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J11121F10 | [1] | LABEL | KOBLABEL |
| 1. | 2432J1369 | [2] | TYPE PLATE | KOB |
| 2. | 2432N1115 | [1] | TYPE PLATE | KOBNAME |
| 3. | 2432T4269 | [1] | TYPE PLATE | KOBNAME |
| 4. | 2432N1117 | [1] | TYPE PLATE | KOBNAME |
| 5. | 2432T4270 | [1] | TYPE PLATE | KOBNAME |
| 6. | 2427Z329D2 | [2] | SHEET | KOBAnti-Slip (400x150mm) |
| 7. | 2427Z329 | [2] | SHEET | KOBAnti-Slip (300x150mm) |
| 8. | 2432T1142D3 | [4] | LABEL | KOB |
| 10. | 2446U228S12 | [1] | LABEL | KOB |
| 11. | 2432N2066 | [1] | LABEL | KOBLUBRICATION |
| 12. | 2432P1054 | [1] | LABEL | KOBLUBRICATION |
| 13. | 2432T1202 | [1] | PLATE | KOB |
| 14. | 2432T1231 | [1] | DATA PLAQUE | KOBDecal, Warning - |
| 16. | 2432T1215 | [1] | DATA PLAQUE | KOBDecal, Caution - To prevent accidents and bodily injury … |
| 18. | 2432T1426 | [1] | PLATE, CAUTION | PLATE, CAUTION |
| 19. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 20. | 2432T1530 | [1] | IDENTITY PLATE | KOB |
| 21. | 2432J1354 | [1] | TYPE PLATE | KOB |
| 22. | 2432T1759 | [1] | PLATE | KOBOPERATION |
| 23. | 2432T2304D16 | [1] | LABEL | KOB |
| 25. | 2432T4141 | [1] | LABEL | LABEL |
| 26. | 2432T4140 | [1] | LABEL | LABEL |
| 27. | 2432N578 | [1] | PLATE | KOB |
| 28. | 2432T2341 | [1] | LABEL | KOBOPERATION |
| 30. | 2432N1097 | [2] | LABEL | KOBDecal, Danger - Stay out of the swing area. |
| 31. | 2432T892 | [1] | LABEL | KOBPLATE, CAUTION, FRONT WINDOW LOCK |
| 32. | 2432T2283 | [1] | LABEL | KOBDecal, Fuel location |
| 33. | 2432P1038 | [1] | TYPE PLATE | KOB |
| 34. | 2432T2486 | [1] | LABEL | KOB |
| 35. | 2432T2485 | [1] | LABEL | KOB |
| 36. | 2432T2304D11 | [2] | LABEL | KOB |
| 37. | 2432T4147 | [1] | LABEL | KOB |
| 38. | 2432T4146 | [1] | LABEL | LABEL |
| 39. | 2432T2487 | [1] | LABEL | KOB |
| 40. | 2432T2342 | [1] | LABEL | LABEL |
| 45. | 2432T4148 | [1] | LABEL | KOB |
| 46. | 2432T4145 | [1] | LABEL | KOB |
| 49. | 2418T10311 | [2] | PLATE | KOBØ30mm round Superseded by part number: 2418T27058 |
| 50. | 2432T4142 | [1] | LABEL | KOB |
| 51. | 2432P1020 | [2] | LABEL | KOB |
| 54. | 2432P1085 | [1] | LABEL | KOB |
| 55. | 2432P1734 | [1] | LABEL | KOBDecal, Warning - Operation of power boost … |
| 58. | 2432P2089 | [1] | LABEL | KOB |
| 59. | 2432N2243 | [1] | LABEL | KOBLIFTING CAPACITIES |
| 60. | 2432T4512 | [1] | LABEL | LABEL |
| 61. | 2432P2090 | [1] | LABEL ANTIFREEZE | LABEL ANTIFREEZE |
| 62. | 2432N2242 | [1] | LABEL | KOBLIFTING CAPACITIES, H/L |
| 63. | 2432N2247 | [1] | LABEL | KOBLIFTING CAPACITIES |
| 64. | 2432N2248 | [1] | LABEL | KOBLIFTING CAPACITIES, H/L |
