| 1. |
48024685
|
[1] |
DIA KIT, HARVESTER
|
COE
Incl 2 - 48
|
| 2. |
47591735
|
[1] |
FRAME
|
ZED
|
| 3. |
87723507
|
[1] |
FRAME
|
ZED
|
| 4. |
47944376
|
[1] |
STOP
|
ZED
|
| 5. |
47944378
|
[1] |
STOP
|
ZED
|
| 6. |
84032863
|
[5] |
ROLLER,108mm OD x 1127mm L
|
ZED
|
| 7. |
9839087
|
[8] |
NYLON BEARING,25.5mm ID x 50mm OD x 30mm Thk
|
ZED
|
| 8. |
9837933
|
[10] |
SPACER,17mm ID x 25.4mm OD x 12.5mm L
|
ZED
|
| 9. |
9837806
|
[4] |
FLANGED BEARING,25mm ID
|
ZED
|
| 10. |
9512549
|
[2] |
ROD
|
ZED
|
| 11. |
84074138
|
[2] |
CHAIN,1190mm L
|
ZED
|
| 12. |
292267
|
[2] |
LAMP
|
ZED
Superseded by part number: 80292267
|
| 13. |
84074054
|
[2] |
SUPPORT
|
ZED
|
| 14. |
84074051
|
[4] |
SUPPORT
|
ZED
|
| 15. |
47538280
|
[2] |
SUPPORT
|
ZED
|
| 16. |
84801337
|
[1] |
ROLLER,108mm OD x 1127mm L
|
ZED
|
| 17. |
84583160
|
[1] |
PLATE
|
ZED
|
| 18. |
84164081
|
[1] |
SUPPORT
|
ZED
|
| 19. |
309308
|
[2] |
BOLT,Hex, M12 x 1.75 x 120mm, Cl 8.8
|
NH
|
| 20. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 21. |
9706685
|
[8] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 22. |
412185
|
[2] |
CARRIAGE BOLT,Short Sq Nk, M16 x 2 x 50mm, Cl 8.8, Full Thd
|
DUB
|
| 23. |
86000441
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 24. |
120047
|
[2] |
CARRIAGE BOLT,M16 x 70mm, Cl 8.8
|
ZED
|
| 25. |
140048
|
[14] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 26. |
100020
|
[12] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 27. |
86595832
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 28. |
120090
|
[2] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 29. |
48017172
|
[2] |
BUSHING
|
ZED
|
| 30. |
140104
|
[4] |
WASHER,26mm ID x 45mm OD x 3mm Thk
|
ZED
|
| 31. |
322358
|
[24] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 32. |
120104
|
[23] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 33. |
84449335
|
[4] |
CABLE TIE,346mm L
|
ZED
|
| 34. |
447336
|
[1] |
WASHER,11mm ID x 25mm OD x 3.99mm Thk
|
ZED
|
| 35. |
120068
|
[1] |
BOLT,Hex, M10 x 40mm, Cl 8.8
|
NH
|
| 36. |
47962336
|
[1] |
MOUNTING PLATE
|
ZED
|
| 37. |
328754
|
[6] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 38. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 39. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 40. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 41. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 42. |
412109
|
[1] |
PIN
|
ZED
|
| 43. |
84300618
|
[1] |
HYDRAULIC CYLINDER
|
ZED
|
| 44. |
378246
|
[3] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 45. |
84814924
|
[2] |
WASHER,16.3mm ID x 31.5mm OD x 1.25mm Thk
|
ZED
|
| 46. |
47931704
|
[1] |
ROLLER
|
ZED
|
| 47. |
47931819
|
[1] |
PIN
|
ZED
|
| 48. |
130007
|
[3] |
COTTER PIN,M4 x 25
|
NH
Superseded by part number: 83903970
|
