| . . | YX15V00003F1 | [1] | HYDRAULIC MOTOR | KOBASSY (PROPELLING) Superseded by part number: YX15V00003F4 |
| . . | YX15V00003F4R | [1] | REMAN-HYD MOTOR | KOBE135SR ASN YY04-06254, E135SRLC ASN YH04-03102, E115SR ASN YV04-03043, ALL Reman For New P/N YX15V00003F1 |
| . . | YX15V00003F4C | [1] | CORE-MOTOR HYDRAULIC | KOBReturn Number |
| . . | YX15V00003F2 | [1] | MOTOR | KOBASSY (PROPELLING) Superseded by part number: YX15V00003F4 |
| . . | YX15V00003F4 | [1] | MOTOR | KOBASSY (PROPELLING) |
| 1. | YW15V00005S001 | [1] | HUB | KOB |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONSPINDLE |
| 6. | YA15V00001S006 | [1] | GEAR | KOB |
| 8. | YW15V00005S008 | [1] | COVER | KOBCover With 10 bolt holes |
| 9. | 2441U829S9 | [3] | SHAFT | KOB |
| 14. | 2441U750S14 | [3] | SEPARATOR | KOB |
| 15. | YW15V00005S015 | [1] | COUPLING | KOB |
| 17. | YW15V00005S017 | [24] | PIN | KOB |
| 19. | YW15V00005S019 | [3] | BOLT | KOB |
| 20. | 2441U524S20 | [3] | SNAP RING | KOBRETAINING |
| 21. | YW15V00005S021 | [2] | BALL BEARING | KOB Superseded by part number: 2441U750S21 |
| 22. | 2441U750S22 | [6] | ROLLER BEARING | KOB |
| 23. | YX15V00003S023 | [6] | BEARING | KOBROLLER |
| 25. | ZR16X03500 | [3] | RING | KOBRetaining -- ID 32.20 x OD 35 x Th 1.6mm |
| 27. | ZD12P00700 | [2] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 29. | YW15V00005S029 | [1] | O-RING,5.33mm Thk x 266.7mm ID, 70 Duro | KOB |
| 30. | YW15V00005S030 | [1] | O-RING | KOB |
| 33. | 2441U496S25 | [2] | PLUG | KOB |
| 35. | YX15V00003S035 | [10] | BOLT | KOBCAP Superseded by part number: YW15V00005S035 |
| 36. | 2441U815S26 | [3] | BALL | KOB |
| 102. | YW15V00005S102 | [1] | SHAFT | KOB |
| 103. | YA15V00001S103 | [1] | PLATE | KOB |
| 107. | YW15V00005S107 | [1] | PLATE | KOB |
| 108. | EN01W00009S108 | [1] | BALL | KOB |
| 109. | YW15V00005S109 | [1] | PLATE | KOB |
| 110. | 2441U532S110 | [2] | WASHER | KOB |
| 111. | EN01W00009S111 | [1] | WASHER | KOB |
| 112. | EN01W00009S112 | [1] | PISTON | KOB |
| 113. | 2441U961S113 | [8] | SPRING | KOB |
| 114. | YW15V00005S114 | [1] | SPRING | KOB |
| 115. | 2441U532S115 | [3] | PLATE | KOB |
| 116. | 2441U532S116 | [3] | PLATE | KOB |
| 117. | EN01W00009S117 | [1] | PLATE | KOB |
| 121. | 2441U995S121 | [2] | PLUG | KOB |
| 124. | 2441U532S123 | [2] | PLUG | KOB |
| 125. | YW15V00005S125 | [2] | STOP | KOB |
| 126. | EN01W00009S153 | [2] | PLUG | KOB |
| 127. | 2441U532S126 | [2] | HYDRAULIC VALVE | KOB |
| 128. | 2441U532S128 | [2] | SPRING | KOB |
| 130. | 2441U532S127 | [2] | SPRING | KOB |
| 132. | EN01W00009S118 | [1] | OIL SEAL | KOB |
| 135. | EN01W00009S128 | [1] | O-RING | KOB |
| 136. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 137. | ZD12P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 138. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 139. | EN01W00009S127 | [1] | O-RING | KOB |
| 140. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 141. | 2441U815S141 | [1] | PIN | KOB |
| 142. | YW15V00005S142 | [2] | PIN | KOB |
| 143. | ZS23C10030 | [8] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP, M10x1.50x30mm Superseded by part number: ZS28C10030 |
| 145. | EN01W00009S121 | [1] | SNAP RING | KOBRETAINING Superseded by part number: 2441U815S145 |
| 146. | YX15V00003S146 | [1] | PLUG | KOB |
| 149. | YW15V00005S149 | [1] | ROLLER CAGE BEARING,25mm ID x 52mm OD x 15mm W | KOB Superseded by part number: 87528160 |
| 150. | EN01W00009S123 | [1] | BEARING | KOBBALL |
| 151. | EN01W00009S124 | [3] | ROLLER | KOBBEARING |
| 154. | PY15V00006S154 | [9] | PLUG | KOB |
| 166. | 2441U995S189 | [1] | SPRING | KOB |
| 167. | EN01W00009S125 | [2] | PIVOT | KOB |
| 169. | YW15V00005S169 | [1] | PLATE | KOB |
| 170. | ZS23C08065 | [4] | CAP,Hex Socket Head, M8 x 65mm | KOBScrew -- M08x1.25x65mm |
| 171. | YW15V00005S171 | [2] | PIN | KOB |
| 174. | 2441U750S171 | [4] | LOCK WASHER | KOB |
| 191. | EN01W00009S171 | [1] | SPRING | KOB(FOR F1, F2 ONLY) |
| 192. | 2441U995S192 | [2] | PLUG | KOB(FOR F1 ONLY) |
| 193. | ZD12P01000 | [2] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 194. | 2441U829S168 | [2] | BALL | KOB |
| 199. | 2441U829S199 | [1] | PLATE | KOB |
| 200. | YX22V00002F1 | [1] | VALVE | KOBASSY, RELIEF, SEE FIG 08-038 |
| 202. | YX15V00003S202 | [2] | PLATE | KOBPLUG (FOR F2, F4 ONLY) |
| . . | EN01W00009S170 | [1] | PISTON | KOBREPAIR KIT, CONSISTS OF REF 161(1), 162(1) (FOR F1, F2) |
| . . | YA15V00001R200 | [1] | REPAIR KIT | KOBCONSISTS OF REF 2(1), 3(1), 19(3) |
| . . | YA15V00001R400 | [1] | REPAIR KIT | KOBCONSISTS OF REF 7(3) |
| . . | YW15V00005R600 | [1] | KIT | KOBREPAIR, CONSISTS OF REF 104(1), 105(9), 106(9), 107(1) |
| . . | YX15V00003R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF 4(1), 5(1), 9(3), 22(6), 23(6) |
| . . | YX15V00003R200 | [1] | REPAIR KIT | KOBCONSISTS OF REF 36(2), 101(1), 121(1), 123(1), 124(2),125(2), 126(2), 127(2), 128(2), 130(2), 136(2), 137(2), 140(2), 146(1), 154(9), 166(1), 179(1), 190(1), 192(2), 193(2), 194(2), 195(2), 199(1) (FOR F1 ONLY) Superseded by part number: YX15V00003R390 |
| . . | YX15V00003R300 | [1] | REPAIR KIT | KOBCONSISTS OF REF 163(1), 164(1) |
| . . | YX15V00003R390 | [1] | REPAIR KIT | KOBCONSISTS OF REF 36(2), 121(1), 123(1), 124(2), 125(2), 126(2), 127(2), 128(2), 130(2), 136(2), 137(2), 140(2), 146(1), 154(9), 166(1), 179(1), 190(1), 193(2), 194(2), 195(2), 199(1),201(1), 202(2) (FOR F2 ONLY) |
| . . | YX15V00003R400 | [1] | REPAIR KIT | KOBCONSISTS OF REF 27(2), 29(1), 30(1), 31(2), 132(1), 135(1), 136(2), 137(2), 138(4), 139(1), 140(2), 193(2) |
| . . | YX15V00003R500 | [1] | REPAIR KIT | KOBCONSISTS OF REF 31(2) |
