| . . | 24100N4172F3 | [1] | TOOL ASSY | TOOL ASSY |
| 1. | ZT12A55000 | [1] | SPECIAL WRENCH | KOBSpanner -- 55mm |
| 2. | ZT12A41000 | [2] | ADJUSTING WRENCH | KOBSpanner, 41mm |
| 3. | ZT12A36000 | [1] | SEAT BACK | KOBSpanner, 36mm |
| 4. | ZT12A27000 | [1] | HEATER | KOB27mm |
| 5. | ZT12A19000 | [1] | GEAR | KOBSpanner, 19mm |
| 6. | ZT12A17000 | [1] | PLUG | KOBSpanner, 17mm |
| 7. | ZT12A10000 | [1] | PLUG | KOBSpanner, 10mm |
| 8. | 2421Z294 | [1] | BLOCK DRIVER | KOBDRIVER Screw, 165mm Long |
| 9. | ZT31B13250 | [1] | HANDLE | KOB |
| 10. | ZT31D13150 | [1] | BAR | KOB |
| 11. | ZT31A17000 | [1] | SOCKET | KOB |
| 12. | ZT31A19000 | [1] | SOCKET | KOB |
| 13. | ZT31A22000 | [1] | SOCKET | KOB |
| 14. | ZT31A27000 | [1] | SOCKET | KOBSOCKET |
| 16. | ZT22A06000 | [1] | KEY, SCREW 06mm | KEY, SCREW 06mm |
| 17. | ZT22A08000 | [1] | KEY | KOBScrew -- 08mm |
| 18. | ZT22A14000 | [1] | KEY | KOB14mm |
| 20. | ZT12D20000 | [1] | WRENCH, ADJUST 24mm Maximum | WRENCH, ADJUST 24mm Maximum |
| 21. | 2421T8 | [1] | TIGHTENER | KOB |
| 22. | ZT71A15000 | [1] | HAMMER | KOB |
| 23. | 4027R1 | [1] | COMPLETE TOOL BOX | KOB, Serial Range: LL1207-LL1287 |
| 24. | 2421Z210 | [1] | HOLDER | KOB |
| 25. | ZT51A15000 | [1] | PLIERS | KOB |
| 26. | 2421R170 | [1] | GENERAL TOOL | KOB, Serial Range: LL1207-LL1329 Superseded by part number: YW01T01014P1 |
| 27. | 2421R140 | [1] | NOZZLE | KOBAdapter -- 1/8"PFx180mm Long |
| 28. | ZT31A24000 | [1] | SOCKET | KOB |
| 31. | 2421R154 | [1] | GREASE GUN | KOB Superseded by part number: EAPN17125A |
| 32. | ZT12A24000 | [1] | HEATER | KOB24mm |
| 33. | 2421Z243 | [1] | KOBELCO CAP | |
| 34. | B16T0442D3 | [1] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| 35. | B16T0442D4 | [1] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 36. | B16T0442D28 | [1] | SHIM,150mm OD x 82mm ID x 2.0mm Thk | KOBID 82 x OD 150 x Th 2.0mm |
| 37. | B16T0442D6 | [1] | SHIM,150mm OD x 82mm ID x 2.3mm Thk | KOBID 82 x OD 150 x Th 2.3mm |
| 38. | B16T0442D13 | [5] | SHIM,160mm OD x 92mm ID x 1.2mm Thk | KOBID 92 x OD 160 x Th 1.2mm |
| 39. | B16T0442D14 | [3] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
| 40. | B16T0442D33 | [3] | SHIM,160mm OD x 92mm ID x 2.0mm Thk | KOBID 92 x OD 160 x Th 2.0mm |
| 41. | B16T0442D15 | [1] | SHIM,160mm OD x 92mm ID x 2.3mm Thk | KOBID 92 x OD 160 x Th 2.3mm |
| 42. | 2420T2747D2 | [1] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 43. | 2420T2747D3 | [1] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 44. | 2420T2747D14 | [1] | SHIM,102mm ID x 170mm OD x 2.0mm Thk | KOBID 102 x OD 170 x Th 2.0mm |
| 45. | 2420T2747D4 | [1] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 64. | 2414T4185 | [1] | TOOL BOX | KOB400x155x110mm, Start Serial: LL1288- |
| 65. | 2421R171 | [1] | GENERAL TOOL | KOBWrench, Filter, Start Serial: LL1330- |
