凯斯零件查询(LB424S XL) - BALER (11/16-) (90.105.240) - LOWER SHIELDS, LARGE TANDEM AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
132 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
48033010
|
[2] |
|
PLATE
|
| 2. |
48033095
|
[2] |
MUDFLAP
|
ZED
|
| 2. |
48033116
|
[2] |
MUDFLAP
|
ZED
|
| 3. |
48033008
|
[2] |
MOUNTING PLATE
|
ZED
|
| 4. |
445395
|
[24] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 5. |
9824326
|
[24] |
WASHER,5.3mm ID x 10mm OD x 1mm Thk
|
NH
|
| 6. |
86619060
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
| 7. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 9. |
86566990
|
[12] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
