神钢零件查询(K909LC) - MARK II EXCAVATOR BTW LL1207 - LL1487 (1/87-12/03) (11-011) - VALVE ASSY, CONTROL (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
775 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1240F1 | [1] | SOLENOID VALVE | KOB |
| . . | 2436U1240F2 | [1] | VALVE ASSY, SOLENOID | VALVE ASSY, SOLENOID |
| . . | 2436U1240F3 | [1] | VALVE ASSY, SOLENOID | VALVE ASSY, SOLENOID |
| 1. | 2436U1240S1 | [1] | HOUSING | |
| 2. | ZD12P01500 | [6] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 4. | 2436U1240S4 | [1] | SPOOL | KOB(FOR F1 ONLY) |
| 5. | 2436U1240S5 | [1] | SPOOL (FOR F2 ONLY) | SPOOL (FOR F2 ONLY) |
| 6. | 2436R688S321 | [3] | SPRING | SPRING |
| 7. | 2436U1159S7 | [1] | COVER | |
| 8. | ZS23C04010 | [8] | SCREW,Hex Socket Head, M4 x 10mm | KOBM04x0.7x10mm |
| 9. | 2436U1159S9 | [3] | SOLENOID VALVE | KOB |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| 11. | 2436U1170S14 | [2] | PIN | KOB |
| 12. | 2436U1240S12 | [1] | SPOOL (FOR F3 ONLY) | SPOOL (FOR F3 ONLY) |
