凯斯零件查询(LB424S XL) - BALER (11/16-) (90.119.025) - PROTECTIONS FLYWHEEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
828 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84284827
|
[1] |
COVER
|
ZED
|
| 2. |
87716226
|
[1] |
EMBLEM
|
FAR
|
| 3. |
190132
|
[2] |
RUBBER WASHER
|
ZED
|
| 4. |
84429041
|
[2] |
LOCKING RING
|
ZED
|
| 5. |
12647004
|
[42] |
WASHER,8.15mm ID x 25mm OD x 2.5mm Thk
|
IMO
|
| 6. |
43133
|
[2] |
BOLT,Hex, M8 x 1.25 x 80mm, Cl 8.8
|
NH
|
| 7. |
322358
|
[41] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
120104
|
[12] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 9. |
84599753
|
[1] |
PLATE
|
ZED
|
| 10. |
412650
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 22mm OD x 1.4mm Thk
|
ZED
|
| 11. |
47485673
|
[1] |
CANVAS
|
ZED
|
| 12. |
84280063
|
[23] |
HALF-HINGE
|
ZED
|
| 13. |
84397010
|
[1] |
SHIELD
|
ZED
|
| 14. |
84397009
|
[1] |
SHIELD
|
ZED
|
| 15. |
47995952
|
[1] |
|
PANEL
|
| 16. |
47995957
|
[1] |
PANEL
|
ZED
|
| 17. |
47407187
|
[7] |
RIVET
|
ZED
|
| 18. |
86624182
|
[7] |
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
|
FOR
|
| 19. |
47734414
|
[1] |
HANDRAIL
|
ZED
|
| 20. |
47994927
|
[1] |
|
BRACKET
|
| 21. |
16045721
|
[4] |
SCREW,Hex, M8 x 125mm, Cl 8.8
|
LEC
|
| 22. |
120061
|
[2] |
BOLT,Hex, M8 x 60mm L, Cl 8.8
|
NH
|
| 23. |
308761
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 24. |
9706690
|
[12] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 25. |
84563638
|
[2] |
BRACKET
|
ZED
|
| 26. |
47361726
|
[1] |
PLATE
|
ZED
|
| 27. |
158188
|
[4] |
PLUG,19mm Hole, 28.6mm OD
|
ZED
|
| 28. |
86619060
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
| 29. |
47994958
|
[1] |
|
BRACKET
|
| 30. |
43127
|
[16] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
