神钢零件查询(K909LC) - MARK II EXCAVATOR BTW LL1207 - LL1487 (1/87-12/03) (11-026) - MOTOR ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
226 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U741F1 | [1] | MOTOR | KOB |
| 12. | 2441U741S12 | [9] | REPAIR KIT | KOBCONSISTS OF REF 121,122 |
| 13. | 2441U741S13 | [1] | REPAIR KIT | KOBCONSISTS OF REF 111,131 |
| 18. | 2441U741S18 | [1] | REPAIR KIT | KOBCONSISTS OF REF 113,123 |
| 20. | 2441U741S20 | [1] | COVER ASSY,VALVE CONSISTS OF REF 303,451 | |
| 23. | 2441U741S23 | [1] | COVER ASSY,FRONT CONSISTS OF REF 304,452 | |
| 31. | 2436U1283F2 | [1] | VALVE PRESSURE RELIE | KOB |
| 101. | 2441U741S101 | [1] | SHAFT | |
| 106. | 2441U741S106 | [1] | SPACER | KOB |
| 107. | 2441U741S107 | [1] | SPACER | |
| 111. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER |
| 113. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 114. | 2441U741S114 | [4] | SPRING | KOBCONED DISK |
| 115. | 2441U741S115 | [1] | SHIM | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 124. | 2441U741S124 | [1] | PLATE | KOBSHOE |
| 131. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE,VALVE |
| 133. | 2441U741S133 | [1] | GUIDE RING | KOB |
| 301. | 2441U741S301 | [1] | CASE | KOB |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER,VALVE |
| 304. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER,FRONT |
| 401. | ZS23C20100 | [2] | SCREW,Hex Socket Head, M20 x 100mm | KOBM20x2.5x100mm |
| 402. | ZS23C20045 | [2] | CAP,Hex Socket Head, M20 x 45mm | KOBScrew -- M20x2.5x45mm |
| 403. | ZS23C12035 | [16] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 431. | ZR16X05500 | [2] | RING | KOBSNAP |
| 437. | ZR26X12000 | [1] | LOCKING RING | KOBRetaining -- ID 124 x OD 127 x Th 4.0mm |
| 443. | 2441U741S443 | [1] | BEARING | KOB |
| 444. | 2441U741S444 | [1] | BEARING | KOB |
| 451. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 452. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| 463. | 2441U741S463 | [2] | PLUG | |
| 464. | 2441U436S468 | [1] | PLUG | KOB |
| 471. | 2441U741S471 | [1] | O-RING | KOB |
| 472. | 2441U741S472 | [1] | O-RING | KOB |
| 474. | 2441U741S474 | [2] | O-RING | KOB |
| 484. | ZD12P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 485. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 491. | 2441U549S491 | [1] | OIL SEAL | KOB Superseded by part number: 24100U84S25 |
| 702. | 2441U741S702 | [1] | PISTON, BRAKE | PISTON, BRAKE |
| 703. | 2441U741S703 | [1] | COUPLING | KOB |
| 706. | 2441U741S706 | [1] | O-RING | KOBO-RING |
| 712. | 2441U741S712 | [4] | SPRING CONED DISK | SPRING CONED DISK |
| 713. | 2441U741S713 | [2] | SEAT,SPRING | |
| 742. | 2441U741S742 | [1] | CLUTCH PLATE | KOB |
| 992. | ZE82T08000 | [2] | PLUG | KOB1/2" PT |
