卡特零件查询（730C） 369-8994: MOUNTING GP-ALTERNATOR & COMPR
广数供应链运营团队, 15 02月, 2025，浏览：
479 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 243-2310 | [2] | COVER | |
| 2. | 333-1207 | [1] | IDLER AS | |
| 3. | 336-4953 | [1] | TENSIONER-BELT | |
| 4. | 279-2589 | [1] | PULLEY AS-IDLER(8-GROOVE) | |
| 5. | 391-0151 | [1] | BRACKET-SUPPORT | |
| 6. | 391-0152 | [1] | BRACKET-SUPPORT | |
| 7. | 5P-8245 | [4] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 8. | 6V-3822M | [2] | BOLT(M10X1.5X35-MM) | |
| 9. | 6V-4249M | [2] | BOLT(M10X1.5X50-MM) | |
| 10. | 6V-5839 | [5] | WASHER(11X21X2.5-MM THK) | |
| 11. | 6V-7981M | [1] | BOLT(M10X1.5X70-MM) | |
| 12. | 6V-8149M | [2] | NUT(M12X1.75-THD) | |
| 13. | 7X-0909M | [2] | BOLT(M12X1.75X140-MM) | |
| | M | | METRIC PART |
