| . . | 24100J9956F1 | [1] | WIRING ASSY,ELEC, Serial Range: LL1207-LL1244 | |
| . . | 24100J9956F2 | [1] | WIRING ASSY,ELEC, Serial Range: LL1245-LL1349 | |
| . . | 24100J9956F3 | [1] | WIRING ASSY,ELEC, Start Serial: LL1350 | |
| 1. | 2479R1368 | [1] | RELAY | KOBRELAY |
| 2. | NSS | [2] | NOT SOLD SEPARAT | CONLIGHT ASSY REF SEE FIG 05-019, Serial Range: LL1207-LL1349 |
| 3. | 2479U240F1 | [1] | HORN | KOBHORN ASSY, Serial Range: LL1245-LL1349 Superseded by part number: CM53S00002F1 |
| 4. | 2479U240F2 | [1] | HORN | KOBHORN ASSY, Serial Range: LL1245-LL1349 Superseded by part number: CM53S00002F2 |
| 5. | 2486R72D5 | [1] | NEG BATTERY CABLE | KOB |
| 6. | 2486R72D10 | [1] | NEG BATTERY CABLE | KOB |
| 7. | 2486R72D3 | [1] | NEG BATTERY CABLE | KOB |
| 8. | 2486R72D4 | [1] | NEG BATTERY CABLE | KOB |
| 9. | 2479U808 | [1] | WIRE HARNESS | KOBWIRING, Serial Range: LL1207-LL1349 |
| 10. | 2479U826 | [1] | HARNESS | KOB, Serial Range: LL1207-LL1244 |
| 11. | 2479Z1005D3 | [1] | WIRE HARNESS | KOB |
| 12. | 2432Z270 | [5] | CLAMP | KOB |
| 13. | 2420Z1188 | [1] | GROMMET | KOB |
| 14. | 2420Z699 | [1] | GROMMET | KOB |
| 15. | 2420R372D19 | [1] | GROMMET | KOB, Serial Range: LL1207-LL1211 |
| 16. | 2456U68F1 | [4] | LAMP | KOB |
| 16-1. | 2456U68S1 | [1] | LENS | KOB |
| 16-2. | 2456U68S2 | [1] | BODY | KOB |
| 16-3. | 2456U68S3 | [1] | PACKING | KOB |
| 16-4. | 2456U68S4 | [2] | BULB | KOBBULB Superseded by part number: 2456U85S4 |
| 16-5. | 2456U68S5 | [4] | SCREW | KOB |
| 17. | 2456U68F2 | [4] | LAMP | KOB |
| 17-1. | 2456U68S1 | [1] | LENS | KOBLENS |
| 17-3. | 2456U68S3 | [1] | PACKING | KOB |
| 17-5. | 2456U68S5 | [4] | SCREW | KOB |
| 17-6. | 2456U68S6 | [1] | BODY | KOB |
| 18. | 2420Z1227D4 | [32] | SCREW | KOBM06x1.0x20mm |
| 20. | 2432R225D1 | [7] | CLIP | KOBClamp, Single -- ID 06 x 29.8mm Long |
| 21. | 2432R225D5 | [7] | CLIP | KOB, Serial Range: LL1207-LL1409 Superseded by part number: ZC46X12011 |
| 22. | 2432R225D6 | [3] | CLIP | KOB |
| 23. | 2432R225D8 | [5] | CLIP | KOBClamp, Single -- ID 19.1 x 51.55mm Long, Serial Range: LL1207-LL1409 Superseded by part number: ZC46X19011 |
| 24. | 2432R225D9 | [3] | CLIP | KOBClamp, Single -- ID 22 x 54mm Long, Serial Range: LL1207-LL1409 Superseded by part number: ZC46X22011 |
| 25. | ZS31C05010 | [1] | BOLT,Phillips Drive, Pan HD, M5 x 10mm | KOBM05x0.8x10mm |
| 26. | ZW26X05000 | [1] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 27. | ZW16K05000 | [1] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 28. | ZN18C06005 | [14] | NUT | KOBM06x1.0mm |
| 29. | ZW26X06000 | [14] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 30. | ZW16K06000 | [4] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 31. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 32. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 33. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 34. | ZW16K08000 | [2] | WASHER,8mm ID x 15.5mm OD x 1.6mm Thk | KOBID 08 x OD 15.5 x Th 1.6mm |
| 35. | ZS18C10014 | [1] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 36. | ZN18C10008 | [21] | NUT | KOBM10x1.50mm, Serial Range: LL1207-LL1409 |
| 37. | ZW26X10000 | [21] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm, Serial Range: LL1207-LL1409 |
| 38. | ZW16K10000 | [4] | WASHER | KOBID 10.5 x OD 18 x Th 2.0mm |
| 39. | 2475R129 | [9] | DIODE | KOB, Serial Range: LL1207-LL1287 |
| 40. | 2432Z290 | [10] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 41. | 2432Z309D1 | [5] | CLAMP | KOB |
| 42. | 2479U1010 | [1] | WIRE HARNESS | KOB, Start Serial: LL1245 |
| 43. | 2479U1009F1 | [1] | HORN,24V, 390HZ | KOBHigh (415Hz), Start Serial: LL1350 Superseded by part number: CM53S00002F1 |
| 44. | 2479U1009F2 | [1] | HORN,24V, 350HZ | KOBLow (390Hz), Start Serial: LL1350 Superseded by part number: CM53S00002F2 |
| 45. | NSS | [2] | NOT SOLD SEPARAT | CONLIGHT ASSY REF SEE FIG 05-020, Start Serial: LL1350 |
| 46. | 2479U1077 | [1] | WIRING HARNESS, Start Serial: LL1350 | WIRING HARNESS, Start Serial: LL1350 |
