纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (06-005) - NAME PLATE INSTAL (MACHINE NAME) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
968 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY22T00099F1 | [1] | NAME PLATE INSTAL (COMMON) | |
| . . | YY22T00099F3 | [1] | NAME PLATE INSTAL (SELECT) | |
| 1. | YY20T01111P1 | [1] | LABEL | KOBLUBRICATION CHART |
| 2. | YY22T00105P1 | [1] | DECAL | KOBNAME PLATE (FOR F1 ONLY), NEW HOLLAND KOBELCO |
| 3. | YY22T00107P1 | [1] | DECAL KIT | KOBNAME PLATE (FOR F1 ONLY), NEW HOLLAND KOBELCO |
| 4. | YY22T00108P1 | [1] | DECAL KIT | KOBNAME PLATE (FOR F1 ONLY), NEW HOLLAND KOBELCO |
| 5. | YY20T01163P1 | [1] | LABEL | KOB(FOR F1 ONLY) |
| 6. | YY20T01162P1 | [1] | LABEL | KOB(FOR F1 ONLY) |
| 9. | YV22T00044P1 | [1] | LABEL | IMONAME PLATE (FOR F3 ONLY), E115SR |
