凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (05.21[01]) - LARGE STEERED TANDEM AXLE, SUSPENSION Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
772 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84215253
|
[1] |
BEAM
|
ZED
|
| 1. |
84215252
|
[1] |
BEAM
|
ZED
|
| 1. |
84215251
|
[1] |
BEAM
|
ZED
|
| 1. |
84215250
|
[1] |
BEAM
|
ZED
|
| 1. |
84226714
|
[1] |
TUBE
|
ZED
|
| 1. |
84226713
|
[1] |
TUBE
|
ZED
|
| 2. |
84218569
|
[2] |
SUSPENSION
|
ZED
|
| 3. |
84100553
|
[4] |
SUPPORT
|
ZED
|
| 4. |
84100552
|
[4] |
INSULATOR BLOCK
|
ZED
|
| 5. |
84100555
|
[16] |
NUT
|
ZED
|
| 6. |
84100545
|
[2] |
SUPPORT
|
ZED
|
| 7. |
84011668
|
[8] |
NUT,M24 x 2, Cl 8.8
|
ZED
Superseded by part number: 11691421
|
| 8. |
84100548
|
[4] |
BRIDGE
|
ZED
|
| 9. |
84100547
|
[4] |
SHIM
|
ZED
|
| 10. |
84100550
|
[2] |
SHAFT
|
ZED
|
| 11. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 11. |
84227805
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 84041875
|
| 12. |
84216778
|
[2] |
CROWN NUT
|
ZED
|
| 13. |
84100554
|
[8] |
BRIDGE
|
ZED
|
| 14. |
300919
|
[2] |
LUBE NIPPLE
|
ZED
Superseded by part number: 84447449
|
| 15. |
84216826
|
[2] |
DUST CAP
|
ZED
|
