纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (02-007) - IDLER ASSY, P/N YX52D00003F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
338 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX52D00003F1 | [1] | IDLER | KOBASSY Superseded by part number: YV52D00002F1 |
| 1. | YX52D00004P1 | [1] | IDLER | KOB |
| 2. | LP52D01003P1 | [1] | SHAFT | KOB |
| 3. | LP52D01004P1 | [2] | BUSHING | KOB |
| 4. | LP52D01009P1 | [2] | COLLAR | KOB |
| 5. | LP52D01006P1 | [2] | PIN | KOB |
| 6. | 2445R441F1 | [2] | SEAL,90mm ID x 114.45mm OD x 33mm Thk | KOBASSY |
| 7. | ZD11G05500 | [2] | O-RING,54.40mm ID x 60.60mm OD x 3.10mm | KOB |
| 8. | ZE82T02000 | [2] | PLUG | KOB |
