纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-002[02]) - COUNTERWEIGHT ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
627 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YV60C00005P1 | [1] | WEIGHT | KOBCOUNTER |
| . . | YX60C00007F1 | [1] | COUNTERWEIGHT INSTAL (STD) | |
| B1. | ZS18C24120 | [4] | SCREW,Hex, M24 x 120mm | KOBCAP |
| B2. | YX60C01001P1 | [4] | WASHER | KOB |
| B3. | LE60C01008D3 | [2] | SHIM | KOB |
| B4. | LE60C01008D4 | [2] | SHIM | KOB |
| B5. | 2420Z1340D2 | [2] | PLUG | KOB |
| B6. | YT60C01007P1 | [3] | PLUG | KOB |
| . . | YX60C00013F7 | [1] | COUNTERWEIGHT INSTAL (NHK, GAIN) | |
| C1. | YX60C00012P1 | [1] | WEIGHT | KOBCOUNTER |
| C4. | LE60C01028P1 | [2] | PLATE | KOB |
| C7. | HS18C20125G1 | [3] | SCREW | KOBCAP |
| C8. | HY26Y21050G4 | [3] | WASHER | KOB |
| C12. | LC22T00069P1 | [1] | NAMEPLATE | KOBNAME PLATE |
| . . | YY60C00041F1 | [1] | COUNTERWEIGHT GROUP | |
| D1. | YY60C01034P1 | [1] | INSULATING PANEL | KOB |
| D2. | YY60C01040P1 | [1] | INSULATING PANEL | KOB |
