凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (06.514[01]) - CABLE HARNESS: 84455721 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
305 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
444852
|
[1] |
TERMINAL CONNECTOR,16 - 20mm
|
ZED
|
| 2. |
335483
|
[1] |
TERMINAL CONNECTOR,4 - 6 mm2
|
ZED
Superseded by part number: 80335483
|
| X001. |
86500035
|
[1] |
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
|
GI
X1 Superseded by part number: 87695607
|
| . . |
84074628
|
[1] |
CABLE TERMINAL
|
L
|
| . . |
900786
|
[1] |
ELEC. TERMINAL PIN,Male, 5 - 8 mm2
|
NH
Superseded by part number: 87697948
|
| . . |
84074256
|
[1] |
TERMINAL CONNECTOR,Male
|
ZED
Superseded by part number: 352506A1
|
| X001B. |
86500036
|
[1] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
X1B
|
| . . |
84807672
|
[1] |
CABLE TERMINAL
|
ZED
|
| . . |
84074257
|
[1] |
CONTACT HOUSING,Female, 9 Pole
|
ZED
|
