凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (06.516[01]) - CABLE HARNESS: 84459691 - NOT FOR NA Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
225 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86500036
|
[1] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
|
| 2. |
441166
|
[1] |
TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm
|
ZED
|
| . . |
441159
|
[1] |
CONTACT HOUSING,Female, 1 Pole
|
ZED
Superseded by part number: 87675193
|
| . . |
430026
|
[1] |
TERMINAL CONNECTOR,1 - 2.5mm
|
ZED
|
| X123. |
426199
|
[1] |
TERMINAL CONNECTOR,Female, 1 - 2.5 mm2
|
ZED
X123
|
| . . |
398225
|
[1] |
MULTIPOLE CONNECTOR,7 Pin
|
ZED
|
| X207. |
86500035
|
[1] |
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
|
GI
X207 Superseded by part number: 87695607
|
| . . |
84074636
|
[1] |
WIRE CONNECTOR,Male
|
ZED
Superseded by part number: 89861350
|
| . . |
9861376
|
[1] |
CONTACT HOUSING
|
GI
Superseded by part number: 87694145
|
| X503. |
335482
|
[1] |
TERMINAL CONNECTOR,1.5 - 2.5 mm2
|
ZED
X503 Superseded by part number: 80335482
|
| . . |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| . . |
84074631
|
[1] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
Superseded by part number: 87695582
|
| . . |
84074638
|
[1] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| . . |
84074630
|
[1] |
CONTACT HOUSING,Male, 2 Pole
|
ZED
|
| . . |
86500166
|
[1] |
ELEC CONNECTOR
|
ZED
Superseded by part number: 225318C1
|
