凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (06.518[01]) - CABLE HARNESS: 84460028 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
238 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| X137. |
86500036
|
[1] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
X137
|
| . . |
84074637
|
[1] |
WIRE CONNECTOR,Female
|
ZED
|
| . . |
84074640
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
Superseded by part number: 86622299
|
| X504. |
86500035
|
[1] |
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
|
GI
X504 Superseded by part number: 87695607
|
| . . |
84074636
|
[1] |
WIRE CONNECTOR,Male
|
ZED
Superseded by part number: 89861350
|
| . . |
9861376
|
[1] |
CONTACT HOUSING
|
GI
Superseded by part number: 87694145
|
