凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (06.526[01]) - CABLE HARNESS: 87526033 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
613 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
444852
|
[1] |
TERMINAL CONNECTOR,16 - 20mm
|
ZED
|
| . . |
335101
|
[1] |
TERMINAL CONNECTOR,4 - 6 mm2
|
ZED
Superseded by part number: 80335101
|
| 2. |
335483
|
[1] |
TERMINAL CONNECTOR,4 - 6 mm2
|
ZED
Superseded by part number: 80335483
|
| . . |
335316
|
[1] |
TERMINAL CONNECTOR,0.3 - 1.3 mm2
|
ZED
|
| . . |
84078783
|
[1] |
FUSE,80A, Midival
|
ZED
|
| . . |
84078784
|
[1] |
FUSE HOLDER
|
ZED
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| X001. |
86500035
|
[1] |
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
|
GI
X1 Superseded by part number: 87695607
|
| . . |
84074628
|
[1] |
CABLE TERMINAL
|
L
|
| . . |
900786
|
[1] |
ELEC. TERMINAL PIN,Male, 5 - 8 mm2
|
NH
Superseded by part number: 87697948
|
| . . |
84074256
|
[1] |
TERMINAL CONNECTOR,Male
|
ZED
Superseded by part number: 352506A1
|
| X201. |
900552
|
[1] |
ELEC. TERMINAL PIN,Male, 1 - 2 mm2
|
NH
X201 Superseded by part number: 87695915
|
| . . |
84074255
|
[1] |
CONTACT HOUSING,Male, 9 Pole
|
ZED
|
