纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-022) - HYD LINES, UPP (SUCTION, DELIVERY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
804 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY30H00002F1 | [1] | LINE | KOBHYD, PUMP |
| 1. | YV30H01005P1 | [1] | TUBE | KOB |
| 2. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOB |
| 3. | YN64H01068D7 | [2] | RUBBER | KOB |
| 4. | YX30H01004P2 | [1] | HOSE | KOB |
| 5. | YX30H01014D1 | [1] | HOSE | KOB |
| 6. | YX30H01012D1 | [1] | HOSE | KOB |
| 7. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 8. | ZD12P02600 | [2] | O-RING | KOB |
| 9. | ZG33F12012 | [1] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB |
| 9-1. | ZD12P02400 | [1] | O-RING | KOB |
| 10. | ZG23F12012 | [1] | HYD CONNECTOR | KOB1 3/16" 12UN-3/4" PT x 48mm Long (Incls. O-Ring ZD12P02400) |
| 11. | ZE13X12000 | [4] | CLAMP | KOBHALF |
| 12. | ZS18C10035 | [8] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 13. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBSCREW |
| 14. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 15. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| 16. | ZC16X09100 | [4] | CLIP | KOB |
| 17. | LC52S00012P1 | [2] | SENSOR | KOBPRESS (H.P.) Superseded by part number: YY52S00033F1 |
| 17-2. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 19. | YN64H01068DD | [2] | RUBBER | KOB |
