纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-030[02]) - CONTROL LINES, REMOTE P/N YY64H00021F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
227 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY64H00021F1 | [1] | CONTROL LINES, VALVE | |
| 1. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 2. | YY35V00006F1 | [1] | VALVE | KOBASSY, SOLENOID |
| 3. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 4. | HH25R06006GE | [1] | ELEC CONNECTOR | KOB |
| 5. | ZH32X04000 | [7] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| 6. | ZH32X06000 | [2] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 7. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB45 |
| 8. | ZW16H10000 | [1] | WASHER | KOB |
| 9. | 2420R349D160 | [1] | HOSE,6.35mm ID x 1600mm L | KOB |
| 10. | ZX23M04220 | [1] | HOSE ASSY. | KOB |
| 11. | 2420R349D265 | [1] | HOSE | KOB |
| 12. | 2420R349D325 | [1] | HOSE | KOB |
| 13. | 2420R349D315 | [1] | HOSE | KOB |
| 14. | 2420R349D320 | [1] | HOSE ASSY. | KOB |
| 15. | 2420R537D055 | [1] | HOSE ASSY.,9.60mm ID x 550mm L | KOB |
| 16. | 2420R537D300 | [1] | HOSE,9.60mm ID x 3000mm L | KOB Superseded by part number: HX21E06300DX |
| 17. | 2420R537D340 | [1] | HOSE ASSY.,9.60mm ID x 3400mm L | KOB |
| 18. | PU13E01010DJ | [1] | TUBE | KOB |
| 19. | PY01P01043D5 | [2] | CABLE TIE,301mm L | KOB |
| 20. | ZS18C10070 | [2] | SCREW,Hex, M10 x 70mm | KOBCAP |
| 21. | ZW16X10000 | [2] | WASHER | KOB |
| 22. | YV64H01019D1 | [1] | RUBBER | KOB |
| 23. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 24. | PY01P01043D6 | [3] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 25. | YY64H01032P1 | [1] | GUIDE | KOB |
| 26. | YY64H01019D1 | [1] | RUBBER | KOB |
| 28. | PU13E01010DL | [1] | TUBE | KOB |
| 29. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| 30. | YY64H01054D1 | [1] | RUBBER | KOB |
