神钢零件查询(K912) - MARK II EXCAVATOR ASN LC-2301 (11/88-12/03) (10-007) - TOOL ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
851 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4194F6 | [1] | TOOL ASSY | |
| 10. | ZT31B13250 | [1] | HANDLE | KOB |
| 11. | ZT31D13150 | [1] | BAR | KOB |
| 12. | ZT31A17000 | [1] | SOCKET | KOB |
| 13. | ZT31A19000 | [1] | SOCKET | KOB |
| 14. | ZT31A24000 | [1] | SOCKET | KOB |
| 15. | ZT31A27000 | [1] | SOCKET | KOB |
| 16. | ZT22A06000 | [1] | KEY, SCREW 06mm | KEY, SCREW 06mm |
| 17. | ZT22A08000 | [1] | KEY | KOBScrew -- 08mm |
| 18. | ZT22A10000 | [1] | KEY | KOB10mm |
| 20. | 2421T8 | [1] | TIGHTENER | KOB |
| 21. | ZT71A15000 | [1] | HAMMER | KOB |
| 26. | 2421Z296 | [1] | ADJUSTING WRENCH | KOBSet -- (8x10(1),12x14(1),13x17(1),19x22(1),24x27(1),30x32(1)) |
| 27. | ZT51A15000 | [1] | PLIERS | KOB |
| 31. | 2414T4185 | [1] | TOOL BOX | KOB400x155x110mm |
| 32. | ZT31A30000 | [1] | SOCKET | KOB |
| 33. | 2421Z294 | [1] | BLOCK DRIVER | KOBDRIVER Screw, 165mm Long |
| 38. | ZT22A14000 | [1] | KEY | KOB14mm |
| 39. | ZT22A05000 | [1] | KEY | KOBScrew -- 05mm |
| 40. | ZT22A17000 | [1] | KEY, SCREW 17mm | KEY, SCREW 17mm |
| 47. | 2421R170 | [1] | GENERAL TOOL | KOB Superseded by part number: YW01T01014P1 |
| 55. | ZT31A22000 | [1] | SOCKET | KOB |
| 56. | 2421R140 | [1] | NOZZLE | KOBAdapter -- 1/8"PFx180mm Long |
| 57. | 2421R145 | [1] | GREASE GUN | KOB Superseded by part number: YT01T01009F1 |
