| . . | YY06H00007F1 | [1] | CONTROL | KOBLINES, PUMP |
| A1. | YN50V00007F1 | [1] | VALVE | KOBASSY, INLINE |
| A2. | ZH22X06000 | [3] | HYD CONNECTOR | KOB |
| A3. | ZH52X04000 | [1] | TEE,30° Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB |
| A4. | ZH32X06000 | [2] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| A5. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOB |
| A6. | ZH42X12000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOB |
| A8. | HH35X04004G3 | [1] | 90 ELBOW | KOB |
| A9. | 2444T2505 | [1] | HYD CONNECTOR | KOB |
| A10. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB |
| A11. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOB Superseded by part number: HX21E06110DX |
| A12. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB |
| A13. | ZX32M12048 | [1] | HOSE | KOB |
| A14. | HH55Q06006G1 | [2] | TEE | KOB |
| A15. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBCap |
| A16. | ZW16X10000 | [3] | WASHER | KOB |
| A17. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB |
| A18. | YY06H01002P1 | [2] | PLUG | KOB |
| A19. | ZH32X04006 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| A20. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| A21. | 2444R1119D070 | [1] | HOSE | KOB |
| A24. | PU13E01002DE | [1] | TUBE | KOB |
| A25. | ZC48X24014 | [1] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| A26. | ZE72X04000 | [1] | PLUG | KOB |
| A28. | YX06H01004D1 | [1] | TUBE | KOB |
| A29. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A30. | 2444Z2891 | [1] | HYD CONNECTOR | KOB |
| A31. | PU13E01002D9 | [1] | TUBE | KOB |
| A32. | YN64H01048P1 | [1] | TEE,90°, PF 3/8" x PF 3/8", O-Ring | KOB |
| A36. | 2418Z1333D27 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 600mm Length | KOBProtective Plastic |
| A37. | 2444Z3155 | [1] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB Superseded by part number: YT42H01128P1 |
| . . | YY62H00003F1 | [1] | CONTROL | KOBLINES, PROPEL |
| B1. | YX30V00004F1 | [1] | VALVE | KOBASSY, PILOT, Serial Range: YV04-03043-YV04-03311 Superseded by part number: YX30V00004F2 |
| B1. | YX30V00004F2 | [1] | PILOT VALVE | KOBASSY, Start Serial: YV04-03312 |
| B2. | LC52S00011P1 | [2] | SENSOR | KOBPRESS (L P.) Superseded by part number: LC52S00019P1 |
| B2-2. | ZD12P01100 | [1] | O-RING | KOB |
| B4. | ZW16K10000 | [4] | WASHER | KOB |
| B5. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB |
| B8. | 2444R1119D045 | [1] | HOSE | KOB Superseded by part number: 2444R1119D046 |
| B9. | 2420R537D300 | [2] | HOSE,9.60mm ID x 3000mm L | KOB Superseded by part number: HX21E06300DX |
| B10. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| B11. | 2420R537D260 | [2] | HOSE,9.60mm ID x 2600mm L | KOB |
| B12. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOB |
| B13. | 2418Z1333D5 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 400mm Length | KOB |
| . . | YT64H00036F1 | [1] | CONTROL | KOBLINES, BLOCK |
| C1. | 2416N6141 | [1] | BLOCK | KOB |
| C4. | ZH32X04000 | [3] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| C5. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| C6. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| C9. | ZE72X06000 | [1] | PLUG | KOB |
| C12. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
