凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (08.01[01]) - PROTECTIONS FLYWHEEL, SUPPORT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
427 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87473974
|
[1] |
SUPPORT
|
ZED
|
| 1. |
87473557
|
[1] |
SUPPORT
|
ZED
|
| 2. |
87471120
|
[2] |
HINGE
|
ZED
|
| 3. |
84120115
|
[1] |
SHIELD
|
ZED
|
| 4. |
87475438
|
[1] |
PLATE
|
ZED
|
| 5. |
87475441
|
[1] |
PLATE
|
ZED
|
| 6. |
84015292
|
[1] |
LATCH
|
ZED
|
| 7. |
86507486
|
[14] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 8. |
322358
|
[22] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 9. |
9706690
|
[20] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 10. |
9837364
|
[4] |
BALL JOINT
|
ZED
Superseded by part number: 9837417
|
| 11. |
9837397
|
[2] |
GAS STRUT
|
ZED
|
| 12. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 13. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 14. |
9837395
|
[1] |
HANDLE
|
ZED
|
| 15. |
86508568
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 16. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 17. |
9706755
|
[8] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 18. |
84100273
|
[2] |
SLEEVE,8.5mm ID x 12.42mm OD x 43.5mm L
|
ZED
|
| 19. |
9839580
|
[2] |
HEX SOC SCREW,M8 x 70mm, Cl 8.8
|
ZED
Superseded by part number: 89839580
|
| 20. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 21. |
84021301
|
[1] |
STUD,M10 x 75mm
|
ZED
|
| 22. |
84000555
|
[2] |
INSULATOR,Bumper
|
ZED
|
| 23. |
86512439
|
[6] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 24. |
120041
|
[4] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 25. |
100097
|
[2] |
JAM NUT,Thin, M8 x 1.25, Cl 04
|
GI
, Start Serial: D724 Superseded by part number: 103889
|
