纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-053[03]) - CONTROLLER GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
943 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV22E00017F1 | [1] | CONTROLLER ASSY (STD) | |
| . . | YV22E00017F2 | [1] | CONTROLLER ASSY (WITH SWING FLASHER) | |
| A1. | YY22E01019P1 | [1] | BOX | KOB |
| A2. | YY22E01006P1 | [2] | BRACKET | KOB |
| A3. | YV14E00012F2 | [1] | HARNESS ASSY, CAB | |
| A3-1. | ZM61C06020 | [4] | BOLT | KOBSEMS |
| A3-2. | ZM61C06016 | [3] | BOLT | KOBSEMS |
| A3-3. | 2427Z1594D003 | [1] | SOFT TRIM | KOB |
| A3-4. | YY14E01068P1 | [1] | HARNESS | KOB |
| A3-4A. | YY73E00001F3 | [1] | FUSE BOX | KOBASSY |
| A3-4Aa. | YN73E00001S001 | [1] | BASE | KOB |
| A3-4Ab. | YN73E00001S002 | [1] | COVER | KOB |
| A3-4Ad. | 2479R655S8 | [11] | FUSE,10 Amp | KOB(10A) Superseded by part number: 87522597 |
| A3-4Ae. | 2479R655S9 | [10] | FUSE | KOB(20A) |
| A3-4Aj. | YY73E01005P1 | [1] | LABEL | KOB |
| A3-5. | 2432R233D1 | [1] | CLIP | KOB |
| A3-6. | ZW16X06000 | [1] | WASHER | KOB Superseded by part number: 86588450 |
| A3-7. | YN03E01001D5 | [6] | CLIP | KOB |
| A5. | LC22E01001D1 | [1] | RESISTOR,16ohm | KOB |
| A6. | YT50E00001F1 | [1] | SWITCH | KOBASSY (SWING PARKING RELEASE) Superseded by part number: YN50S00047P1 |
| A7. | YN50S01003P1 | [1] | SWITCH | KOBASSY (KPSS RELEASE) |
| A8. | EN24S00008P1 | [8] | RELAY | KOB |
| A9. | 2427Z1594D006 | [1] | TRIM PANEL | KOB |
| A10. | 2427Z1594D008 | [2] | PROTECTION STRIP | KOBTRIM Superseded by part number: S16539-17000 |
| A11. | 2427Z1594D028 | [2] | TRIM PANEL | KOB |
| A12. | YT22E01006P1 | [1] | LABEL | KOB |
| A13. | YV22E01002P1 | [1] | LABEL | KOB |
| A14. | ZM41C04012 | [1] | BOLT | KOBSEMS |
| A15. | ZM61C06012 | [12] | BOLT | KOBSEMS (FOR F1 ONLY) |
| A16. | ZM61C06030 | [3] | BOLT | KOBSEMS |
| A17. | YY24S00001P1 | [1] | RELAY | KOBFLASHER (WITH SWING FLASHER) (FOR F2 ONLY) Superseded by part number: YY24S00001P2 |
| A18. | YV14E01016P1 | [1] | ELEC CONNECTOR | KOB Superseded by part number: AMP917981-6 |
| A20. | YN25S00001P1 | [1] | TIMER | KOB |
| A22. | ZM61C06025 | [1] | BOLT | KOBSEMS |
| A31. | LC24S00001P1 | [1] | RELAY | KOB |
| B1. | ZM22C10025 | [4] | BOLT | KOBSEMS |
| B2. | YT22E01026P1 | [1] | INDICATOR | KOB |
| B3. | 2432R233D3 | [1] | CLIP | KOB |
