凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (08.19[01]) - LOWER SHIELDS, LARGE TANDEM AXLE, RH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
892 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87474083
|
[1] |
FENDER
|
ZED
|
| 2. |
87471071
|
[1] |
COVER PLATE
|
ZED
|
| 3. |
87484964
|
[1] |
SUPPORT
|
ZED
|
| 4. |
87756530
|
[1] |
DOOR
|
ZED
|
| 5. |
87491481
|
[1] |
SHIELD
|
ZED
, Serial Range: -C703 Superseded by part number: 84145466
|
| 5. |
84145466
|
[1] |
SHIELD
|
ZED
, Start Serial: D704
|
| 6. |
86507486
|
[31] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
322358
|
[31] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
9706690
|
[31] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 9. |
336455
|
[3] |
PLUG
|
ZED
|
| 10. |
84145479
|
[2] |
SLAT
|
ZED
, Start Serial: D704
|
| 11. |
84145484
|
[1] |
CANVAS
|
ZED
, Start Serial: D704
|
| 12. |
84145491
|
[1] |
FIXING PLATE
|
ZED
, Start Serial: D704
|
| 13. |
445395
|
[8] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
, Start Serial: D704
|
