| . . | 24100J11023F4 | [1] | CONTROL ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONLEVER ASSY,CONTROL |
| 2. | 2406T1702 | [2] | PLATE | KOB |
| 3. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 4. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 5. | 2406T1672 | [4] | YOKE | KOB Superseded by part number: 2406T2278 |
| 5. | 2419T3784D1 | [5] | PIN | KOB |
| 7. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 8. | 2419R9D4 | [8] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 10. | 2416P8717 | [1] | BRACKET | KOB |
| 10-5. | 2416T13022 | [1] | BRACKET | KOB |
| 10-5B. | 2405R61D7 | [2] | BUSHING | KOB Superseded by part number: 2405U104D012008 |
| 11. | ZS23C08020 | [4] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 12. | ZW22K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 13. | 2406T2896 | [2] | LEVER | KOB |
| 13-2. | 2405R61D7 | [1] | BUSHING | KOB Superseded by part number: 2405U104D012008 |
| 14. | 2406T1762 | [2] | YOKE | KOB |
| 15. | 2419T3841D1 | [4] | PIN | KOB |
| 16. | ZW16X10000 | [14] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 17. | ZP16D03020 | [2] | COTTER PIN | KOB |
| 18. | 2419T3757D3 | [2] | PIN | KOB |
| 19. | 2414N3804 | [1] | STAND CONTROL | |
| 19-12. | 2405R61D11 | [2] | BUSHING | KOBBUSHING |
| 20. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 21. | 2414N3564 | [2] | BOX | KOB |
| 23. | 2406Z317 | [2] | KNOB | KOB |
| 24. | 2406P4068 | [2] | LEVER | KOB |
| 25. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 2S. | 2418T19956 | [2] | TUBE, NYLON | TUBE, NYLON |
| 27. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 28. | ZP15K02012 | [2] | COTTER PIN | KOB Superseded by part number: ZP15K02035 |
| 29. | 2419T4776 | [2] | SHAFT | KOB |
| 30. | ZW26K06000 | [4] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| 31. | 2418T17873 | [2] | PLATE | KOB |
| 32. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 33. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 36. | 2418Z726D3 | [19] | WASHER, LOCK | KOBID 06 x OD 12.2 x Th 1.5mm Superseded by part number: ZW26X06000 |
| 37. | 2418T19135 | [1] | PLATE | KOB |
| 38. | 2406T2385 | [2] | YOKE | KOB |
| 39. | ZS23C06020 | [2] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 40. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 41. | 2419R9D3 | [4] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 42. | 2421R169F1 | [2] | LOCK | KOB |
| 43. | 2414P6019 | [2] | COVER | KOB |
| 44. | 2414P6022 | [1] | COVER | KOB |
| 45. | 2420Z1227D5 | [9] | SCREW | KOBM06x1.0x30mm |
| 46. | 2418Z725D3 | [17] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 47. | 2414P6021 | [1] | COVER | KOB |
| 48. | 2414P6020D1 | [1] | COVER | KOB |
| 49. | 2414P6020D2 | [1] | COVER | KOB |
| 50. | 2414P6023 | [2] | COVER | KOB |
| 51. | 2420Z1227D6 | [4] | SCREW | KOBM06x1.0x35mm |
| 52. | 2414P6013 | [1] | COVER | KOB |
| 53. | 2420Z1229D2 | [6] | SCREW | KOB |
| 54. | 2414N3939 | [1] | COVER | KOB |
| 55. | 2420Z1227D4 | [4] | SCREW | KOBM06x1.0x20mm |
| 56. | 2420Z1188 | [2] | GROMMET | KOB |
| 57. | 2479Z1422 | [1] | LIMIT SWITCH | KOB |
| 58. | 2419T3841D2 | [2] | PIN | KOB |
| 59. | 2418Z725D4 | [6] | WASHER | KOBID 04 x OD 08.0 x Th 0.8mm |
| 60. | 2418Z726D4 | [6] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 62. | 2414T2962 | [2] | COVER | KOB |
| 63. | 2414T2963 | [1] | COVER | KOB |
| 64. | ZS18C08040 | [1] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 65. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 70. | 2414P6345 | [2] | COVER | KOB |
| 71. | 2414P6717 | [1] | COVER | KOB |
| 82. | 2406R223D1 | [2] | FLEXIBLE CONTROL | KOB |
| 83. | 2414N3584 | [1] | BOX | BOX |
| 84. | 2414T4200 | [1] | COVER | COVER |
| 85. | 2420Z1226D1 | [4] | SCREW | KOB |
| 86. | 2418Z726D2 | [4] | LOCK WASHER | KOBID 05 x OD 9.2 x Th 1.3mm Superseded by part number: ZW26X05000 |
| 87. | ZS23C06016 | [2] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm Superseded by part number: ZS28C06016 |
| 89. | 2414P6371 | [1] | CUP COVER | KOB |
| 90. | 2416P14092 | [1] | BRACKET | KOB |
| 90-5. | 2416T13022 | [1] | BRACKET | KOB |
| 90-5B. | 2405R61D7 | [2] | BUSHING | KOB Superseded by part number: 2405U104D012008 |
