纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-064) - ELECTRICAL ASSY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
359 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX03E00002F3 | [1] | ELEC ASSY, UPP YV04-03043, Serial Range: -YV04-03084 | |
| . . | YX03E00002F6 | [1] | ELEC ASSY, UPP YV04-03085 to | |
| 1. | YN24S00003F1 | [1] | RELAY | KOBASSY, BATTERY |
| 2. | CM53S00002F1 | [1] | HORN | KOBASSY |
| 3. | CM53S00002F2 | [1] | HORN | KOBASSY |
| 4. | YX03E01008P2 | [1] | BRACKET | KOB, Serial Range: YV04-03043-YV04-03084 Superseded by part number: YX03E01011P1 |
| 5. | YX03E01007P1 | [1] | PLATE | KOB, Serial Range: YV04-03043-YV04-03084 Superseded by part number: YX03E01012P1 |
| 6. | 2432R233D2 | [1] | CLIP | KOB37x12x40mm |
| 7. | ZM11C08016 | [6] | BOLT | KOBSEMS |
| 8. | ZM61C06016 | [2] | BOLT | KOBSEMS |
| 9. | YX03E01010P2 | [1] | RUBBER YV04-03043, Serial Range: -YV04-03084 | |
| 10. | ZM22C08030 | [2] | BOLT | KOBSEMS |
| 11. | ZM22C08020 | [2] | BOLT | KOBSEMS |
| 13. | YY03E01019P1 | [1] | HARNESS | KOB |
| 14. | 4056R4F1 | [1] | LAMP | KOBASSY, ROOM |
| 14-1. | 4056Z19D1 | [1] | LIGHT | KOB |
| 15. | YY03E01001P2 | [1] | U-BRACKET | KOB |
| 16. | YT50S00005P1 | [1] | SWITCH | KOB |
| 17. | ZM61C05020 | [2] | SCREW | KOBSEMS |
| 18. | ZN18C05004 | [2] | NUT | KOB |
| 19. | ZW16K05000 | [2] | WASHER | KOB |
| 20. | ZW26X05000 | [2] | LOCK WASHER | KOBLOCK |
| 21. | YN03E01001D4 | [2] | CLIP,33mm L | KOB |
| 22. | YX03E01011P1 | [1] | BRACKET | KOBYV04-03085 to |
| 23. | YX03E01012P1 | [1] | PLATE | KOBYV04-03085 to |
| 24. | YX03E01013P1 | [1] | RUBBER JOINT | KOBRUBBER YV04-03085 to |
