凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (08.28[01]) - TWINE BOXES LH SUPPORT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
910 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84444396
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84819698
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C867
|
| 2. |
84319736
|
[1] |
SUPPORT
|
ZED
, Start Serial: D868
|
| 3. |
87729022
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84819382
|
[1] |
SUPPORT
|
ZED
|
| 4. |
84819378
|
[1] |
SUPPORT
|
ZED
|
| 5. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 6. |
9706690
|
[8] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 7. |
87331610
|
[1] |
GUIDE
|
ZED
|
| 8. |
84444540
|
[1] |
WASHER,35mm ID x 45mm OD x 2mm Thk
|
ZED
|
| 9. |
370004
|
[1] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
| 10. |
87332566
|
[4] |
FIXING PLATE
|
ZED
, Serial Range: -C927
|
| 10. |
84421934
|
[4] |
LEAF SPRING
|
ZED
, Start Serial: D928
|
| 11. |
338949
|
[15] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 12. |
43140
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 13. |
140045
|
[15] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 14. |
100016
|
[15] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
86507486
|
[9] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 16. |
86511323
|
[4] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 17. |
378243
|
[2] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 18. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 19. |
84074027
|
[2] |
SHIM
|
ZED
|
