纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-066[05]) - HARNESS ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY13E00009F5 | [1] | HARNESS ASSY, UPP YV04-03043, Serial Range: -YV04-03314 | |
| . . | YY13E00009FD | [1] | HARNESS ASSY, UPP, Start Serial: YV04-03315 | |
| A1. | YX13E01006D1 | [1] | CABLE | KOB |
| A2. | 2486R89D5 | [1] | CABLE | KOB |
| A3. | YN13E01053D3 | [1] | CABLE | KOB |
| A4. | YX13E01020D1 | [1] | CABLE | KOB |
| A6. | LE13E01006P1 | [1] | HARNESS | KOB |
| A7. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| A8. | ZW26X08000 | [3] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A9. | 2432R233D1 | [2] | CLIP | KOB |
| A10. | ZM61C06012 | [2] | BOLT | KOBSEMS |
| A11. | YX13E01015P1 | [1] | GROMMET | KOB |
| A12. | YX13E01012P1 | [1] | GROMMET | KOB |
| A13. | PY13E01039P1 | [1] | RUBBER | KOB |
| A14. | PY01P01043D4 | [10] | CABLE TIE,4.80mm W x 251mm L | KOB |
| A15. | YN03E01001D4 | [5] | CLIP,33mm L | KOB |
| A16. | ZW16X08000 | [2] | WASHER | KOB |
| A17. | YX13E01016P1 | [1] | GROMMET | KOB |
| A18. | YT13E01039P1 | [1] | GROMMET | KOB |
| A20. | 2432R233D3 | [2] | CLIP | KOB |
| A21. | ZS18C08016 | [3] | SCREW,Hex, M8 x 16mm | KOBCAP |
| A22. | ZW16X10000 | [1] | WASHER | KOB |
| A24. | YY13E01072P1 | [1] | HARNESS | KOB |
| . . | YY14E00012F1 | [1] | HARNESS ASSY, CAB | |
| B1. | YY14E01036P2 | [1] | HARNESS | KOB |
| B3. | YY14E01039P1 | [1] | HARNESS | KOB |
| B4. | YN03E01001D5 | [3] | CLIP | KOB |
| B6. | YX14E01004P1 | [2] | GROMMET | KOB |
| B7. | PY01P01043D7 | [1] | CABLE TIE,4.80mm W x 445mm L | KOB, Serial Range: YV04-03043-YV04-03109 |
| . . | YY13E00010F6 | [1] | HARNESS | KOBASSY, UPP (PLATE, FLOOR) |
| C3. | LE13E01005P1 | [1] | CABLE,100mm L | KOB |
| C10. | YY13E01088P2 | [1] | HARNESS | KOB |
| . . | YV16E00002F1 | [1] | HARNESS | KOBHARNESS ASSY, ENGINE |
| D1. | YV16E01003P1 | [1] | HARNESS | KOB |
| D3. | YX16E01006P1 | [1] | BRACKET | KOB |
| D4. | ZS18F10014 | [1] | SCREW | KOBCAP |
| D5. | ZS18C10014 | [1] | SCREW,Hex, M10 x 14mm | KOBCAP |
| D6. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| D8. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| D9. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| D10. | ZW16P05000 | [1] | WASHER | KOB |
| D11. | ZS18C05010 | [1] | SCREW,Hex, M5 x 10mm | KOBCAP |
| D12. | ZW26X05000 | [1] | LOCK WASHER | KOBLOCK |
| E1. | YY03Z00013P1 | [1] | SCHEMATIC, ELEC (NOT IN SERVICE) | |
