纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (00-003) - NUT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
645 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | ZA93N10000 | [1] | NUT | KOBTUBE NUT; TYPE: AMC (mm); TUBE SIZE (Ø): 10; B: 19 |
| . . | ZA93N15000 | [1] | TUBE NUT | KOBTUBE NUT; TYPE: AMC (mm); TUBE SIZE (Ø): 15; B: 27 |
| . . | ZA93N18000 | [1] | NUT | KOBTUBE; TYPE: AMC (mm); TUBE SIZE (Ø): 18; B: 32 |
| . . | ZA93N22000 | [1] | TUBE NUT | KOBTUBE; TYPE: AMC (mm); TUBE SIZE (Ø): 22; B: 36 |
| . . | ZA93N28000 | [1] | TUBE NUT | KOBTUBE; TYPE: AMC (mm); TUBE SIZE (Ø): 28; B: 41 |
| . . | ZA93N35000 | [1] | TUBE NUT | KOBTUBE; TYPE: AMC (mm); TUBE SIZE (Ø): 35; B: 55 |
| . . | ZF93N06000 | [1] | NUT | KOBTUBE NUT; TYPE: IHARA (mm); TUBE SIZE (Ø): 6; B: 14 |
| . . | ZF93N08000 | [1] | NUT | KOBTUBE NUT; TYPE: IHARA (mm); TUBE SIZE (Ø): 8; B: 17 |
| . . | ZF93N10000 | [1] | NUT | KOBTUBE; TYPE: IHARA (mm); TUBE SIZE (Ø): 10; B: 19 |
| . . | ZF93N12000 | [1] | NUT | KOBTUBE NUT; TYPE: IHARA (mm); TUBE SIZE (Ø): 12; B: 22 |
| . . | ZF93N15000 | [1] | NUT | KOBTUBE NUT; TYPE: IHARA (mm); TUBE SIZE (Ø): 15; B: 27 |
| . . | ZF93N18000 | [1] | NUT | KOBTUBE; TYPE: IHARA (mm); TUBE SIZE (Ø): 18; B: 32 |
| . . | ZF93N22000 | [1] | NUT | KOBTUBE; TYPE: IHARA (mm); TUBE SIZE (Ø): 22; B: 36 |
| . . | ZF93N28000 | [1] | TUBE NUT | KOBTUBE; TYPE: IHARA (mm); TUBE SIZE (Ø): 28; B: 41 Superseded by part number: ZA93N28000 |
| . . | ZF93N32000 | [1] | NUT | KOBTUBE NUT; TYPE: IHARA (mm); TUBE SIZE (Ø): 32; B: 50 |
| . . | ZF93N35000 | [1] | NUT | KOBTUBE; TYPE: IHARA (mm); TUBE SIZE (Ø): 35; B: 55 |
| . . | ZF93N38000 | [1] | NUT | KOBTUBE; TYPE: IHARA (mm); TUBE SIZE (Ø): 38; B: 60 |
