神钢零件查询(K912) - MARK II EXCAVATOR ASN LC-2301 (11/88-12/03) (08-010) - INSTAL, COVER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
505 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1664F2 | [1] | INSTAL,COVER | |
| . . | 24100P1664F4 | [1] | INSTAL,COVER | |
| 1. | 2416T9878 | [3] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOB |
| 2. | 2416T13218 | [2] | U-BRACKET | KOB |
| 4. | 2432Z290D3 | [2] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 5. | 2414P4100D1 | [1] | COVER | KOB(RH) |
| 6. | 2414P4100D2 | [1] | COVER | KOB(LH) |
| 7. | ZS18C10020 | [4] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 8. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 9. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 10. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 11. | 2456U74F1 | [2] | LIGHT ASSY. | KOB(F2)(P.424-01) Superseded by part number: 2456U74F3 |
| 12. | 2479Z1039 | [1] | WIRE HARNESS | KOB |
