纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-046) - CANOPY ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
663 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW06C00036F1 | [1] | CANOPY | KOBCANOPY ASSY |
| A1. | PW06C01174P1 | [1] | SUPPORT | KOBSUPPORT |
| A2. | PW06C01126P1 | [1] | SUPPORT | KOB |
| A3. | PW41C00017P1 | [1] | HANDRAIL | KOBHANDRAIL |
| A4. | ZS18C16065 | [1] | SCREW,Hex, M16 x 65mm | KOBCAP |
| A5. | ZS18C16100 | [1] | SCREW,Hex, M16 x 100mm | KOBCAP |
| A6. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBCAP |
| A7. | ZS18C12055 | [8] | SCREW,Hex, M12 x 55mm | KOBCAP |
| A8. | ZS18C10040 | [1] | SCREW,Hex, M10 x 40mm | KOBCAP |
| A9. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBCAP |
| A10. | ZW26X16000 | [2] | WASHER | KOB |
| A11. | ZW26X12000 | [10] | WASHER | KOB |
| A12. | ZW26X10000 | [1] | LOCK WASHER | KOB |
| A13. | ZW16H16000 | [2] | WASHER | KOB |
| A14. | ZW16H12000 | [10] | WASHER | KOB |
| A15. | ZW16H10000 | [1] | WASHER | KOB |
| A16. | PM06C01096P1 | [8] | RUBBER | KOB |
| A17. | PM06C01042P1 | [2] | WASHER | KOB |
| A18. | PW06C01088P1 | [2] | PLATE | KOB |
| A19. | 2418T22593 | [4] | WASHER | KOB |
| A22. | PW20T01079P1 | [1] | PLATE | KOBNUMBER |
| A23. | PB06C01093D1 | [8] | RIVET | KOB |
| A24. | PV20T01018P1 | [1] | IDENTITY PLATE | KOBPLATE, NUMBER |
| A26. | 2420Z1340D1 | [4] | PLUG | KOB |
| A27. | PM03M01339P1 | [1] | RUBBER | KOB |
| . . | PW80E00006F1 | [1] | LIGHT | KOBLIGHT INSTAL |
| B1. | PW11E01026D4 | [1] | HARNESS | KOBHARNESS |
| B2. | PW80S00003F1 | [1] | LIGHT ASSY. | KOBSEE FIGURE 01-050 |
| B3. | ZN17F12007 | [1] | NUT | KOB |
| B5. | ZW16X12000 | [1] | WASHER | KOB |
| . . | PW22T00169F1 | [1] | NAME PLATE INSTAL | |
| C1. | PW20T01082P1 | [1] | LABEL | KOB |
