纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-053) - SEAT INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
837 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW25M00027F1 | [1] | SEAT INSTAL | |
| 1. | PW25M01073P2 | [1] | COVER | KOBCOVER |
| 2. | PW25M00015F1 | [1] | SEAT BELT,48mm W x 1250mm L, Black | KOBSAFETY BELT Superseded by part number: YN25M00081F1 |
| 6. | PA41C01005D2 | [1] | BOLT (STEP) | KOB |
| 7. | PW25M00014F1 | [1] | SEAT | KOBASSY |
| 8. | ZW16X08000 | [4] | WASHER | KOB |
| 10. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 11. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 12. | PA03M01093D2 | [4] | BOLT | KOB Superseded by part number: ZM27C08020 |
