神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (02-003[01]) - CAB ASSY (FOR NORTH EUROPE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
367 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6107F3 | [1] | CAB ASSY(FOR NORTH EUROPE) | |
| 2. | 2427U317 | [1] | CABIN DOOR | KOB |
| 3. | 2420Z1035 | [2] | HINGE | KOB |
| 4. | ZS18C10028 | [6] | CAPSCREW,Hex, M10 x 28mm | KOBSCREW M10x1.50x28mm Superseded by part number: ZS18C10030 |
| 5. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 6. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 11. | 2427Z536D2 | [1] | GLASS | KOB |
| 12. | 2427Z537D2 | [1] | GLASS | KOB |
| 13. | 2408Z147 | [1] | HOOK | KOB |
| 14. | 24100J6107S14 | [2] | NUT | KOB |
| 15. | 24100J6107S15 | [2] | WASHER | KOB |
| 16. | 2414Z271 | [1] | COVER | KOB |
| 17. | 24100J6107S17 | [8] | BOLT | KOBSCREW |
| 18. | 2427R477 | [1] | PAD | |
| 19. | 24100J6107S19 | [1] | STRAINER ELEMENT | KOB |
| 21. | 2406R232 | [1] | HANDLE | KOB |
| 22. | 24100J6107S22 | [2] | BOLT | KOBSCREW |
| 23. | 24100J6107S23 | [1] | GLASS | KOB |
| 24. | 2416R225 | [1] | SEAL | KOB |
| 25. | 2416R224 | [1] | SEAL | KOB |
| 26. | 2420R563D1 | [2] | GROMMET | KOB |
| 27. | 2421R166 | [1] | LOCK | KOB |
| 28. | 24100J6107S28 | [2] | SCREW | KOBSCREW Superseded by part number: 2420T5780D2 |
| 29. | 24100J6107S29 | [1] | SCREW | KOB |
| 30. | 24100J6107S30 | [3] | WASHER | KOB Superseded by part number: ZW26X05000 |
| 31. | 2427R633F1 | [1] | HANDLE | KOB |
| 31-1. | 2427R633S1 | [1] | HANDLE | HANDLE |
| 31-2. | 2420Z1030 | [2] | KEY | KOB Superseded by part number: YN50S01010P1 |
| 31-3. | 2427R633S3 | [1] | PACKING | |
| 31-4. | 2427R633S4 | [1] | PACKING | PACKING |
| 32. | 24100J6107S32 | [2] | NUT | KOB Superseded by part number: ZN18C06005 |
| 33. | 24100J6107S33 | [1] | REGULATOR | REGULATOR |
| 34. | 24100J6107S34 | [4] | SCREW | KOBSETSCREW Superseded by part number: ZM41C06012 |
| 35. | 2416R227 | [1] | U-BRACKET | KOB |
| 36. | 24100J6107S36 | [1] | RUBBER, SPONGE | RUBBER, SPONGE |
| 37. | 24100J6107S37 | [2] | RUBBER | KOB |
| 38. | 2406R234 | [1] | HANDLE | KOB |
| 39. | 24100J6107S39 | [2] | GROMMET | GROMMET |
| 40. | 24100J6107S40 | [2] | SCREW | KOB |
| 41. | 2406R233 | [1] | HANDLE | KOB |
| 42. | 24100J6107S42 | [1] | STRIKER PLATE | KOB |
| 43. | 24100J6107S43 | [1] | PLATE | KOB |
| 44. | 24100J6107S44 | [2] | SCREW | KOB |
| 45. | 24100J6107S45 | [1] | SCREW | KOB |
| 46. | 2432Z454 | [2] | SEAL | |
| 47. | 2416Z468D2 | [1] | RUBBER SEAL | KOB |
| 60. | 2427R485D2 | [1] | GLASS | KOB |
| 61. | 2427Z535D2 | [1] | GLASS | KOB |
| 62. | 2427R484D2 | [1] | GLASS | KOB |
| 63. | 2427Z539D2 | [1] | GLASS | KOB |
| 64. | 2427Z540D2 | [1] | GLASS | KOB |
| 65. | 2406R235 | [1] | HANDRAIL | |
| 67. | NSS | [1] | NOT SOLD SEPARAT | CONGLASS |
| 68. | 24100J6107S68 | [6] | BOLT, SET | BOLT, SET |
| 69. | 2427R634 | [1] | HANDRAIL | |
| 70. | 24100J6107S70 | [4] | SCREW | KOBBOLT, SET |
| 71. | 2406R231 | [1] | HANDLE | KOB |
| 72. | 24100J6107S72 | [3] | BOLT, SET | BOLT, SET |
| 73. | 2427Z543 | [1] | TERMINAL CONNECTOR | KOB |
| 74. | 24100J6107S74 | [2] | SETSCREW | SETSCREW |
| 75. | 24100J6107S75 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 10mm | KOBSCREW Superseded by part number: ZS31C03010 |
| 76. | 24100J6107S76 | [2] | NUT | NUT |
| 77. | 2427P1838 | [1] | POCKET | |
| 78. | 24100J6107S78 | [4] | SETSCREW | |
| 79. | 2414Z272 | [2] | COVER | KOB |
| 81. | 2427R479 | [11] | PAD | |
| 82. | 2418Z712 | [11] | WASHER | KOB |
| 83. | 24100J6107S83 | [11] | BOLT SCREW | BOLT SCREW |
| 84. | 2479Z950 | [1] | WIRE HARNESS | KOB |
| 85. | 2479Z952 | [1] | HARNESS | |
| 86. | 2416Z47D10 | [1] | RUBBER | |
| 87. | 2416Z472D9 | [1] | RUBBER | KOB |
| 88. | 2416Z472D8 | [1] | RUBBER SLEEVE | KOB |
| 89. | 2416Z472D5 | [1] | RUBBER | RUBBER |
| 90. | 2416Z472D4 | [1] | RUBBER SLEEVE | KOB |
| 91. | 2416Z473D3 | [1] | RUBBER | RUBBER |
| 92. | 2416Z220D12 | [1] | RUBBER SEAL | KOB |
| 93. | 2416Z220D13 | [1] | RUBBER SEAL | KOB |
| 94. | 2416Z472D3 | [1] | RUBBER SLEEVE | KOB |
| 96. | 2479R703 | [1] | WIPER ARM | KOB Superseded by part number: 2488R249 |
| 97. | R79P0021D2 | [1] | WIPER BLADE | KOB Superseded by part number: 2488Z8D4 |
| 98. | 2456Z316 | [1] | LIGHT | KOBLIGHT, ROOM |
| 99. | 24100J6107S99 | [2] | SCREW | KOB |
| 100. | 2427R627D2 | [1] | CATCH | KOB |
| 101. | 24100J6107S101 | [4] | SET SCREW | KOB |
| 102. | 24100J6107S102 | [2] | SCREW | KOBSETSCREW Superseded by part number: ZM41C06012 |
| 103. | 2427R626 | [1] | ASH TRAY | KOB |
| 104. | 24100J6107S104 | [2] | SCREW | KOB |
| 105. | 2416Z464 | [2] | STOP | KOB |
| 106. | 24100J6107S106 | [2] | NUT | KOB Superseded by part number: ZN18F10008 |
| 107. | 24100J6107S107 | [2] | WASHER | KOB Superseded by part number: ZW16X10000 |
| 108. | 2427Z534 | [1] | LH DOOR LOCK | KOB |
| 109. | 2408T302 | [1] | HOOK | |
| 110. | 24100J6107S110 | [2] | SCREW | KOB |
| 111. | 2416Z466 | [2] | STOP | KOB |
| 112. | 2416Z469D1 | [1] | RUBBER SEAL | KOB |
| 113. | NSS | [1] | NOT SOLD SEPARAT | CONMOTOR, WIPER |
| 114. | 2416Z469D2 | [2] | SEAL, RUBBER | SEAL, RUBBER |
| 115. | 2416Z469D3 | [2] | SEAL, RUBBER | SEAL, RUBBER |
| 116. | 2416Z465 | [2] | STOP | KOB |
| 117. | 24100J6107S117 | [4] | BOLT, SET | BOLT, SET |
| 119. | 24100J6107S119 | [2] | RUBBER, CUSHION | RUBBER, CUSHION |
| 120. | 2416Z471D2 | [1] | RUBBER SLEEVE | KOB |
| 121. | 2427T863 | [1] | PLATE | KOB |
| 122. | 24100J6107S122 | [4] | SETSCREW | SETSCREW |
| 123. | 24100J6107S123 | [1] | SCREW | KOB |
| 124. | 2405Z153D4 | [1] | BUSHING | BUSHING |
| 125. | 2427P1836 | [1] | WEATHERSTRIP | KOB |
| 127. | 2427Z546D2 | [1] | GLASS | KOB |
| 128. | 2427R631 | [1] | COVER | KOB |
| 129. | 24100J6107S129 | [5] | BOLT | KOB |
| 130. | 2427Z545 | [2] | BRACKET | KOB |
| 132. | 2427R630D2 | [2] | RUBBER SLEEVE | KOB |
| 133. | NSS | [1] | NOT SOLD SEPARAT | CONWINDOW, FR. |
| 134. | 2410006107S134 | [6] | NUT | |
| 135. | 24100J6107S135 | [6] | WASHER | WASHER |
| 136. | 24100J6107S136 | [6] | WASHER, LOCK | WASHER, LOCK |
| 137. | 24100J6107S137 | [2] | SCREW | |
| 138. | 24100J6107S138 | [2] | GROMMET | GROMMET |
| 139. | 2416R223 | [2] | BRACKET | KOBBRACKET, LATCH |
| 140. | 2427Z538 | [2] | BRACKET | KOBBRACKET, LATCH |
| 141. | 2427R478 | [1] | PAD | |
| 142. | 24100J6107S142 | [4] | WASHER | |
| 143. | 24100J6107S143 | [4] | SCREW | |
| 145. | 2432Z456 | [1] | STRAINER ELEMENT | KOB |
| 146. | 2432R221 | [1] | STRAINER ELEMENT | KOB |
| 147. | 2432R220 | [1] | STRAINER ELEMENT | KOB |
| 148. | 243Z2455 | [1] | SCREEN | |
| 149. | 24100J6107S149 | [1] | STRAINER ELEMENT | KOB |
| 153. | 24100J6107S153 | [4] | NUT | KOB Superseded by part number: 24100J6107S160 |
| 154. | 24100J6107S154 | [4] | WASHER | WASHER |
| 155. | 24100J6107S155 | [4] | LOCK WASHER | KOB Superseded by part number: 83990583 |
| 157. | 2427U322 | [1] | CAB | |
| 158. | 2479P578 | [1] | PAD | |
| 160. | 24100J6107S160 | [2] | NUT | KOB |
| 161. | 24100J6107S161 | [2] | LOCK WASHER | KOB Superseded by part number: 83990583 |
| 162. | 24100J6107S162 | [2] | LOCK WASHER | KOB Superseded by part number: ZW16X08000 |
| 165. | 24100J6107S165 | [4] | LOCKWASHER | |
| 166. | 24100J6107S166 | [4] | WASHER | |
| 167. | 24100J6107S167 | [1] | FINISHER | |
| 170. | 24100J6107S170 | [1] | BUSHING | KOB |
| 172. | 24100J6107S172 | [2] | RUBBER SEAL | KOB |
| 173. | 24100J6107S173 | [2] | RUBBER SEAL | KOB |
| 174. | 24100J6107S174 | [1] | RUBBER SEAL | KOB |
| 177. | 24100J6107S177 | [2] | STOPPER, RUBBER | STOPPER, RUBBER |
| 178. | 24100J6107S178 | [2] | NUT | KOB Superseded by part number: ZN18F10006 |
