凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (18.84193332[01]) - DIA : ROTOR SIDE FILLER PLATES KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
292 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
84193332
|
[1] |
SERVICE KIT
|
ZED
|
| 1. |
87583469
|
[1] |
PLATE
|
ZED
LH
|
| 2. |
87583466
|
[1] |
PLATE
|
ZED
RH
|
| 3. |
84181581
|
[1] |
PLATE
|
ZED
|
| 4. |
14441321
|
[4] |
HEX SOC SCREW,M6 x 16mm, Cl 8.8
|
NH
Superseded by part number: 84814920
|
| 5. |
412649
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk
|
ZED
|
| 6. |
86500688
|
[4] |
NUT,Hex, M6 x 1.0, Cl 10.9
|
WIN
|
| 7. |
87742349
|
[2] |
HEX SOC SCREW
|
ZED
|
| 8. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 9. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
