神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (02-017) - COVER ASSY, UNDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
696 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3885F1 | [1] | COVER ASSY, UNDER | |
| 1. | 2414P4749D1 | [1] | COVER | KOB |
| 2. | 2414P4750D1 | [1] | COVER | KOB |
| 3. | 2414P4751D1 | [1] | COVER | COVER |
| 4. | 2414P4508 | [1] | COVER | |
| 5. | 2414P4509 | [1] | COVER | KOB |
| 6. | 2414T3343 | [2] | COVER | KOB |
| 21. | ZS18C12035 | [35] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 22. | ZW26X12000 | [35] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 23. | 2418T10357 | [35] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
